EN - 14

ENGLISH

2.4 - UNIT ASSEMBLY

The maximum length allowed for the pipes is 1 m, the pipes must be internally smooth and no

bends can be made.

It is necessary to use the grilles provided, or grilles which keep the same features.

2.4.1 - Drilling the wall

To operate, the unit requires two holes to be drilled in the wall, positioned as indicated on the drilling template;

the holes must be 162 mm in diameter.

• ItispossibletoinstalltheunitUNICOPROINVERTERinsteadofaunitUNICOSKYorUNICOSTAR

or UNICO SMART or UNICO INVERTER without modifying the already existing holes, exception made

for the small condensation drain hole.

In this case, in order not to penalize performances, remove the insulating material possibly present in

the air expulsion hole. The anchoring brackets need new drilling too.

• Drillthewallusingthepropertoolstofacilitateyourjobandpreventexcessdamageordisturbanceto

your client.

The best tools for drilling large holes in walls are special drills called core borers with very high twisting

torque and adjustable rotating speed depending on the diameter of the hole to be drilled.

• Topreventthecreationoflargeamountsofdustandrubbleduetodrilling,thecoreborercanbetted

with a vacuum system applied by means of suction cups to the drilling zone.

• Todrilltheholes,proceedasfollows:

- Place the supplied drill jig (M) against the wall observing the minimum distances from the ceiling,

theoorandfromthesidewallsindicatedonthejigitselfwhichcanbekeptinthecorrectposition

usingadhesivetape(Y)(g.4).

- Use a small drill or punch to mark, with extreme care, the exact centre of each of the holes to be

drilled(g.4).

- Using a core boring head measuring 162 mm

to drill the two holes for entry and exit of the air.

Drill the foregoing holes tilted slightly downwards to prevent water from being fed back through

the ducts (g. 5).

Most of the removed material is expelled outwards, therefore make sure that it

does not hit any person or object when it falls out.

In order to avoid as much as possible outer plaster breaking, it is necessary to

proceed carefully with the last part of hole execution, decreasing pressure on

core borers.

• Drilltheholes,previouslymarked,forthewallplugsrelatedtothexingbrackets(g.6).
