Ø160mm

Fig. 5.l

Fig. 5.m

H=min. 60mm

Fig. 5.n

Fig. 5.o

Spirit level

5.j Preparethesurfacewheretheunitistobemounted.Makesurethatthesurfaceisat,levelledandthatitsupportsthe

weightoftheunit.Performtheinstallationinaccordancewithlocalrulesandregulations.Usethewallxingbracketas

templatetoindicatewheretodrilltheholesinthewall:makesureitisatspiritlevel.Useappropriatescrewsandwallplugs

(not supplied) to ﬁx the wall ﬁxing bracket.

5.k Fix the 2 spacers on the back of the unit.

5.l Hook the unit at its bracket.

5.m Make sure it is at spirit level and ﬁx it by means of the safety screw.

5.n Connectthecondensationdrainjoints(G3/4”M)placedinthebottomsideoftheunittoaU-bend(orsimilar)onthe

condensation drainage pipe. In case close the non-used joint by means of the supplied drain stopper. Make sure this

operation is well done in accordance to the best practice in order to assure water and air tightness.

5.o Connect the unit to the duct system. Make sure that all necessary accessories are used to create a functional ventilation

solution.

 Connecttheunitelectricallyaccordingto§5.4.Checkthatitstartsupcorrectly.
