8 MAINTENANCE AND SERVICE

WARNING

MakesurethatspecicwarningsandcautionsinChapter2arecarefullyread,understoodandapplied!

Maintenance can be carried out by the user.

Service must be performed only by an authorized installer and in accordance with local rules and regulations.

Questionsregardinginstallation,use,maintenanceandservice of the unit shouldbeansweredbyyourinstallerorplaceof

purchase!

8.1 Components list

G4 FILTER - EXTRACT AIR

G4FILTER-SUPPLYAIR

HEATEXCHANGER

CONDENSATIONDRAINAGE

THERMISTOR

FAN,INTAKEAIR

FAN,EXHAUSTAIR

TERMINALBOX

CONTROLCABLE

POWERSUPPLYCABLE

CONDENSATIONTRAY

Fig. 8.a Internal components

7.2 Remote Enable

Itallowstoactivate/deactivatetheunitfromremotebymeansofavolt-freecontactbyconnectingtheIn1inputasperg.5.g.

Toenablethisfunctionitisnecessarytoactondipswitch8.

7.3 Modbus control

TheunitcanbecontrolledviaModbus(ModbusRTUoverRS485).Forspecication,contactourcustomerservice.

DIP8 Remote Enable

0 disable

1 enable
