WARNING

Makesurethatthemainssupplytotheunitisdisconnectedbeforeperforminganyinstallation,service,maintenanceor

electrical work!

8.2 Description of Components

Fans

ThefanshaveexternalrotormotorsofECtypewhichcanbesteplesslycontrolledindividuallybetween10-100%.Themotor

bearingsarelifetimelubricatedandmaintenancefree.Itispossibletoeasilydisconnectandreplacethefansifnecessary.

Filters

The2ltersareoflterqualityG4forboththesupplyairandextractairlter.

Theltersneedtobecleanedregularly(andreplacedwhenpolluted)duringmaintenance.Newsetsoflterscanbeacquired

fromyourinstallerorwholesaler.

Heat exchanger

Theunitisequippedwithahighlyefcient,counter-owplateheatexchanger.Supplyairtemperatureisthereforenormally

maintained without adding additional heat. The heat exchanger is removable for cleaning and maintenance during service.

Condensation drainage

Dependingontherelativehumidityintheextractair,condensationmayoccuronthecoldsurfacesoftheheatexchanger(Table

6.b). The condensate water is led out through drainage pipe.

Thermistor

Temperature probe to implement temperature dependent functions.

•Keep the unit surface free from dust.

•Onceevery3months(fixedperiod),theunitwarnstheusertoperformthefiltermaintenance(Fig.7.b-).Theactualneed

toperformthisoperationmayvarydependingonindoorandoutdoorambientconditions.

•Cleanthefiltersevery3monthswithavacuumcleaner(Fig.8.b-c-d).

•Press the CTRL-V1 button (Fig. 7.b) to reactivate the ﬁlter alarm.

•Replacethefilterseveryyear.

8.3 Maintenance

SCHEMI ELETTRICI

MESSA IN SERVIZIO

FUNZIONAMENTO

MANUTENZIONE ORDINARIA

Fig. 8.b

Fig. 8.c

MANUTENZIONE ORDINARIA

MANUTENZIONE STRAORDINARIA

Fig. 8.d
