Shut down your system if active.
Turn off the power to the system, and disconnect the power cord. Refer to the system documentation for instructions. Before
you install the ConnectX-6 Lx card, make sure that the system is disconnected from power.
(Optional) Check the mounting bracket on the card.
If required for your system, replace the full-height mounting bracket that is shipped mounted on the card with the supplied
low-profile bracket. Refer to Bracket Replacement Instructions.
3.7 Bracket Replacement Instructions
The ConnectX-6 Lx card is usually shipped with an assembled high-profile bracket. If this form factor is suitable for your
requirements, you can skip the remainder of this section and move to Installation Instructions. If you need to replace the high-profile
bracket with the short bracket that is included in the shipping box, please follow the instructions in this section.
To replace the bracket you will need the following parts:
The new brackets of the proper height
The 2 screws saved from the removal of the bracket
Removing the Existing Bracket
Using a torque driver, remove the two screws holding the bracket in place.
Separate the bracket from the ConnectX-6 Lx card.
Save the two screws.
Installing the New Bracket
Place the bracket onto the card until the screw holes line up.
Screw on the bracket using the screws saved from the bracket removal procedure above.
3.8 Installation Instructions
This section provides detailed instructions on how to install your adapter card in a system.
Connect the adapter Card in an available PCI Express x16 slot in the chassis.
Step 1: Locate an available PCI Express x16 slot and insert the adapter card to the chassis.
Step 2: Applying even pressure at both corners of the card, insert the adapter card in a PCI Express slot until firmly seated.
Secure the adapter card to the chassis.
Due to risk of damaging the EMI gasket, it is not recommended to replace the bracket more than three times.
Be careful not to put stress on the LEDs on the adapter card.
Do not force the bracket onto the adapter card.
Use a torque driver to apply up to 2 lbs-in torque on the screws.
Please note that the following figures are for illustration purposes only.
Do not use excessive force when seating the card, as this may damage the chassis.
