16
Mellanox Technologies
•
•
•
•
•
•
1.
A system with a PCI Express slot of corresponding bus width is required for installing the card.
3.3.1.1 Airflow Requirements
ConnectX-6 Lx adapter cards are offered with two airflow patterns: from the heatsink to the network ports.
Please refer to the Specifications section for airflow numbers for each specific card model.
3.3.2 Software Requirements
See Operating Systems/Distributions section under the Introduction section.
Software Stacks - Mellanox OpenFabric software package MLNX_OFED for Linux, WinOF-2 for Windows, and
VMware. See the Driver Installation section.
3.4 Safety Precautions
The adapter is being installed in a system that operates with voltages that can be lethal. Before opening the case of the system,
observe the following precautions to avoid injury and prevent damage to system components.
Remove any metallic objects from your hands and wrists.
Make sure to use only insulated tools.
Verify that the system is powered off and is unplugged.
It is strongly recommended to use an ESD strap or other antistatic devices.
3.5 Unpacking the Package
Check against the package contents list that all the parts have been sent. Check the parts for visible damage that may have occurred
during shipping. Please note that the cards must be placed on an antistatic surface.
Category Qty. Item
Cards 1 ConnectX-6 Lx adapter card
Accessories 1 Adapter card short bracket
1 Adapter card tall bracket (shipped assembled on the card)
3.6 Pre-Installation Checklist
Verify that your system meets the hardware and software requirements stated above.
For proper operation and performance, please make sure to use a PCIe slot with a corresponding bus width and that can
supply sufficient power to your card. Refer to the Specifications section of the manual for more power requirements.
All cards in the system should be planned with the same airflow direction.
Please note that if the card is removed hastily from the antistatic bag, the plastic ziplock may harm the EMI fingers on the
networking connector. Carefully remove the card from the antistatic bag to avoid damaging the EMI fingers.
