Kompass FX3 Multimedia Playback Software User Manual
www.novastar.tech
19
Add Outputs
To synchronize output images, please refer to Graphics Card Mosaic to complete relevant
configurations.
Add and bind outputs automatically
After startup, Kompass FX3 will automatically detect the graphics card connectors and then
complete the adding and binding of those detected connectors. All the connectors are
displayed in the output list on the left.
When you need to change the binding relations between the output connectors and screens,
click to change the output name, connector binding and resolution.
Add and bind outputs manually
When more graphics cards are installed on the control PC or you want to change the connector
quantity in a saved project file, you can select to add the outputs manually.
Click in the output list area to add an output.
Figure 5-2 Add and edit outputs
Name: Change the current output name.
Connector: Select the desired output connector from the drop-down list or change the
connector binding relation. Here take Figure 5-2 as an example to illustrate.
− 1: Connector number of the graphics card (1 indicates the connector 1 of the graphics
card.)
− G1: Graphics card 1
− 1920×1080: Output resolution of the current connector of the graphics card
