11. MENUS | 57
SOUND MENU
Hold SHIFT and press SOUND (Program 2) to access the Sound menu.
Use the PAGE 3 and 4 buttons to navigate between pages. The
PROGRAM dial is used to change settings, and soft buttons to access
additional settings (as described above), where applicable. Press EXIT
(Shift) to leave the menu.
1 - PROGRAM LEVELS
Adjusts the total output level of the currently loaded Program by
adjusting all of its Layer levels. Note that the Program needs to be
stored for the adjustment to stick.
2 - PIANO PEDAL NOISE LEVEL
Sets the level of the Pedal Noise that can be turned on for selected
pianos, if a Nord Triple Pedal is connected to the Stage 4.
Range: +/- 6 dB (0 dB default)
3 - PIANO STRING RES LEVEL
Sets the level of the String Resonance feature that can be turned on for
selected pianos (acoustic Med, Lrg and XL sizes).
Range: +/- 6 dB (0 dB default)
4 - ORGAN KEYBOARD TRIGGER POINT
This setting changes how the Organ is triggered by the keyboard. With
“High” selected the sound is triggered before the key is fully depressed,
which is more similar to how a real B3 and other organ models work.
Range: High (Default), Low
5 - B3 ORGAN TONEWHEEL MODE
Sets the level of tonewheel crosstalk and cable leakage artifacts of the
B3 organ model.
Range: Clean, Vintage 1 (default), Vintage 2
6 - B3 ORGAN CLICK LEVEL
This sets the level of the Key Click for the B3 organ model.
Range: Normal (default), High
7 - ROTARY BASS/HORN LEVEL
This parameter sets the balance between the bass rotor and treble horn,
defined as a percentage.
Range: 70/30, 60/40, 50/50 (default), 40/60 and 30/70
8 - ROTARY ROTOR SPEED
This determines the speed of the rotary speaker woofer rotor.
Range: Low, Normal (default), High
9 - ROTARY ROTOR ACCELERATION
This determines the acceleration and retardation time of the rotary
speaker woofer rotor.
Range: Low, Normal (default), High
10 - ROTARY HORN SPEED
This determines the speed of the rotary speaker treble horn.
Range: Low, Normal (default), High
11 - ROTARY HORN ACC (ACCELERATION)
This determines the acceleration and retardation time of the rotary
speaker treble horn.
Range: Low, Normal (default), High
AUX KB
Hold SHIFT and press AUX KB (Program 4) to access the Aux KB
(Auxilliary Keyboard) menu. Use the PAGE 3 and 4 buttons to navigate
menu pages. The PROGRAM dial is used to change settings, and soft
buttons to access additional settings (as described above), where
applicable. Press EXIT (Shift) to leave the menu.
i Remember to Store the selected Program for Aux KB settings to
be retained.
i The Aux KB MIDI Channel is set in the MIDI menu.
1 - AUX KEYBOARD ENABLE
This setting determines whether the Aux KB functionality is enabled for
the currently selected Program. Configurations made on the second
page of this menu require Aux Keyboard Enable to be set to “On”, in
order to have any effect.
Range: Off (default), On
2 - AUX KEYBOARD LAYERS
Use the Organ, Piano and Synth soft buttons and turn the Program
dial to adjust the configuration for Layers in each Section respectively.
As an example: To control Layer B of the Organ from the auxilliary
keyboard, set Organ to “-B”. Layers that are not part of the Aux KB
configuration are represented with a dash (“-”).
Range Organ: -- (default), A-, -B, AB
Range Piano: -- (default), A-, -B, AB
Range Synth: --- (default), A--, -B-, --C, AB-, A-C, -BC, ABC
3 - KEYBOARD CURVE
This setting determines the velocity scaling of incoming MIDI Notes on
the Aux KB channel. Depending on if the auxilliary keyboard has a non-
or fully weighted action, and depending on the manufacturer it may be
necessary to adjust this setting in order to achieve appropriate control
when playing sounds on the NS4.
Range: Soft, Medium (default), Hard
