56 | NORD STAGE 4 USER MANUAL OS V1.4X
Menu “soft buttons” correspond to the top row of Program buttons
(1-4). This particular menu page only contains three soft buttons.
11
MENUS
The menus, accessed in the central Program area as seconday (Shift)
functions to Program buttons, provide a wide range of settings related
to all aspects of the Nord Stage 4 functionality. Settings that are made
in the menus will take immediate effect, and will be stored until they are
changed again.
i The MIDI Local On/Off setting is an exception and always reverts to
Local Control On every time the Nord Stage 4 is powered up.
Most settings are global, meaning that they apply regardless of which
program is currently loaded, while others – such as Per Program Output
Routing settings and Extern and Aux KB menu settings – are stored per
Program.
Enter a menu by holding SHIFT and pressing the corresponding
Program button. Menus are navigated with the PAGE 3 and 4 buttons
and settings are changed with the PROGRAM dial.
Exit the menus by pressing EXIT (Shift).
i The Organize function is described in the Program chapter, on
page 44 .
SOFT BUTTONS
One menu page may contain several related settings, in which case
“soft buttons” – shown at the bottom of the display and controlled with
the Program 1-4 buttons – are used for focusing a particular setting.
SYSTEM MENU
Hold SHIFT and press SYSTEM (Program 1 button) to access the
System menu settings. Use the PAGE 3 and 4 buttons to navigate
between menu pages. Soft buttons are used to access additional
settings where applicable. When done, press EXIT (Shift) to leave the
menu.
1 - MEMORY PROTECT
The memory protection setting is set to On when a Nord Stage 4 leaves
the factory, to prevent accidental overwriting of programs or Synth
presets. Setting this to Off enables all Store operations. Menu settings
and the eight Live programs are not affected by this setting.
Range: On (default), Off
2 - GLOBAL TRANSPOSE
This setting allows for transposing the entire Nord Stage 4 in semitone
steps. This setting will be added to any on-panel transpose value stored
with a program.
Range: +/- 6 semitones (default value is “None”)
3 - FINE TUNE
Fine Tune adjusts the pitch of the Nord Stage 4 in finer increments.
Range: +/- 50 Cents (+/- half a semitone). Default value is “0”
4 - LED INTENSITY
The panel LEDs can be set to either low or high intensity, which can be
useful for adapting to different lighting conditions.
Range: Low, High (default)
5 - RESET ALL SETTINGS
This operation restores all menu settings (System, Sound, Output, Ped-
al, MIDI and Extern) to their default values. Settings that are stored per
program, such as Aux KB assignments and Output Bus settings per
Section/Layer are not affected.
Press the Reset soft button (Program 4) and confirm with “Yes”
(Program 3 button) to restore all menu settings to factory default
values.
6 - VERSION AND MODEL INFO
The Version and model info menu page shows the full version number
of the currently installed OS (Operating System) and, when turning the
Program dial, the hardware (HW) version of the instrument.
Use the Program dial to switch between Version and HW info
Control Pedal Type
Fatar SL 75%
Type Func Gain
PEDAL SETTINGS 1/7
