10. MIDI | 55
MESSAGES
The following MIDI messages can be transmitted and received by the
Nord Stage 4:
• Note On and Note Off messages are transmitted and received.
• Pitch Bend messages are transmitted and received.
From the MIDI Menu (see page 59), it can be determined whether the
Nord Stage 4 should transmit and/or receive Control Change messages.
• If a Control/Expression pedal is connected to the Organ Swell Input,
this is transmitted and received as Controller 4.
• If a Control/Expression pedal is connected to the Control Pedal Input,
this is transmitted and received as Controller 11 (Expression).
• If a sustain pedal is connected to the Sustain Pedal Input, this is
transmitted and received as Controller 64 (Sustain Pedal).
• A Nord Triple Pedal 2 connected to the Triple Pedal jack also transmits
Sustain Pedal information as Controller 64.
• Almost all other controls (knobs and buttons) on the front panel are
also transmitted and received as Control Change or NRPN messages.
This can be used for recording front panel actions into a MIDI
sequencer. For a full list of which parameters correspond to which
Controller number, refer to page 66.
KEYBOARD VELOCITY
The Nord Stage 4 can transmit and receive Keyboard Velocity
messages. Organ sounds will always be played back at nominal
level regardless of incoming MIDI Velocity data. Release velocity is
transmitted, but ignored on MIDI In.
AFTERTOUCH
The Nord Stage 4 keyboard can transmit Aftertouch messages
(sometimes referred to as channel pressure). This is done by applying
more pressure on a key while it is held down, which generates a signal
that can be used to control parameters.
PROGRAM CHANGE OPERATIONS
Program Change messages are used both for Program and Live
banks as well as for the Synth, Piano and Organ Preset Library banks
– identified by which Bank MSB number is being used. Changing
Programs and Presets respectively on the Nord Stage 4 will send
Program Change messages according to the table below – as long as
Program Change is set to be sent in the MIDI menu that is.
The implementation is designed such that one MIDI LSB bank
addresses as many Nord Stage 4 banks as possible, given the number
of programs within each bank.
Prog Live Synth Piano Organ
Bank MSB (CC#0) 0 1 2 3 4
Bank LSB (CC#32) 0-3 0 0-3 0 0
Program Change 0-127 0-7 0-127 0-127 0-127
An incoming message addressing a Preset will select that Preset for the
targeted Section but will not activate the Section, if it is currently turned
off.
i A Program Change message that reaches the Nord Stage 4
unaccompanied by Bank Select messages will take effect in the
currently selected Program bank.
In the MIDI Menu, you can select if the Nord Stage 4 should send and/
or receive program Change messages on the Global channel. See page
61 for further details.
l If you want to transmit program change messages to external units
without altering the state of the Nord Stage 4, use the Program
Change feature of the Extern Mode.
LOCAL CONTROL ON/OFF
Local Control Off can be used to “disconnect” the keyboard and the
panel on the Nord Stage 4 from its sound engines. Turn Local Off if
you experience “double-triggered” notes when you play; both from the
keyboard internally and via the MIDI “loop”. Local On/Off is set in the
MIDI menu, which is described on page 59.
! Apart from standard Control Change messages, certain panel
controls use NRPN messaging to achieve its functionality over
MIDI. Make sure that the NRPN setting in the MIDI menu is set to
“Send/Receive” if operating the Nord Stage 4 in Local Control Off
mode.
PANIC
If you experience hanging notes when using the
Nord Stage 4 in a MIDI setup, or if all current sound
should be terminated for other reasons, use the PANIC
(Shift+Transpose) function. This will execute an internal
“All Notes Off” message, and reset incoming CC
messages.
