9. EFFECTS | 51
TO ROTARY
The TO ROTARY setting sends the focused Layer to the Rotary Speaker
effect, which has its controls placed at the far left of the panel (see
further down).
Other effects can still be used as usual, but note that the Rotary
Speaker is the last effect unit in the effects chain, so any other effects
that are applied to the Layer will be placed before the Rotary Speaker.
LP 24 FILTER
The LP24 filter is a resonant 24 dB per octave low-pass filter. Use the
morphable FREQ knob to adjust the cutoff frequency of the filter, and the
RES knob to set the amount of resonance around the cutoff point.
l The LP24 filter can be used as an alternative pedal Wah effect, by
morphing its Cutoff frequency with an attached Control Pedal and
adjusting the Resonance to taste.
HP 24 FILTER
The HP24 filter is a resonant 24 dB per octave high-pass filter The
morphable FREQ knob adjusts the cutoff frequency of the filter, and the
RES knob controls the amount of resonance around the cutoff point.
l The Bass and Treble equalizer bands, as well as the Drive effect are
available for both the HP24 and the LP24 effect settings.
COMPRESSOR
The COMPRESSOR effect reduces the dynamic
range of the sound, making low levels louder
and high sound levels more quiet. This produces
a tight, punchy sound and makes the overall
level easier to control in a live mix situation. The
Compressor is activated with its ON button.
The AMOUNT knob controls the amount of
compression applied.
The Compressor can be set to GLOBAL mode
(Shift + On) which applies it to all Layers of all
three Sections.
FAST MODE
The FAST mode (Shift + Amount knob) makes the Compressor recover
quicker after being triggered. With high Compressor Amount this will
create a “pumping” and more obviously compressed sound.
REVERB
The REVERB unit simulates the
natural sound reflections in various
acoustic environments. There are six
Reverb Types of various lengths and
densities, indicated by the LEDs in
the six-way selector.
Reverb Types on the left side of
the selector all have a VARIATION,
described further down. Types on the
right side can all be set to CHORALE,
which increases the pitch modulation in the Reverb signal, for a more
lively sound. Variation/Chorale is activated with Shift+Selector button.
The Reverb can be set to GLOBAL mode (Shift+On) which applies it to
all Layers of all three Sections.
The morphable DRY/WET control sets the balance between the
unprocessed and the processed signal.
l The Dry/Wet control goes all the way to fully wet at its max
position, a sound which can be very effective both for morph
effects, or when blending Layers.
REVERB TYPES
Type Description
SPRING
The Spring setting reproduces the sound of a
traditional spring reverb tank, a common feature on
tonewheel organs, in guitar amplifiers and in many
other kinds of equipment. The VARIATION provides
a different character and increases the length of the
spring for a longer Reverb time.
BOOTH
Booth represents a small room with very short
decay time. VARIATION increases the pre-delay
time, which delays the wet signal in relation to the
dry sound. This can be used to better preserve
articulation, even with higher Amount settings.
ROOM
In Room mode the Reverb has the character of a
room with a relatively short decay time. Here too,
the VARIATION adds a longer pre-delay time.
STAGE
The Stage Reverb has a medium length decay
time and a natural sounding room ambience.
CHORALE mode increases the pitch modulation of
the reverb for a more lively sound.
HALL
The Hall setting has the response and character
of a spacious hall, with a long decay. CHORALE
mode increases the pitch modulation of the reverb
for a more lively sound.
CATH
The Cathedral is a very large and immersive
reverb, with a very long decay time. CHORALE
mode increases the pitch modulation for a more
lively sound.
The BRIGHT or DARK mode can be used for all Types to alter the
frequency response of the Reverb. Set to Bright, low frequencies are
slightly dampened and more high frequency content is preserved in the
Reverb signal. The Dark mode instead dampens high frequencies.
