50 | NORD STAGE 4 USER MANUAL OS V1.4X
intense with each delay tap. For each effect there is a VARIATION,
activated by pressing Shift+Selector button.
The ENS (Ensemble), VIBE and CHOR (Chorus) effects, including their
variations, are based on their counterparts in the MOD 2 effects unit.
The stereo FLAM effect produces a ping pong delay with offset left and
right channels. This is useful at short delay times for room effects, or for
more complex sounds at longer delay times. The variation doubles the
time shift between the channels from 20 to 40 ms.
The SPACE effect introduces reverb-like diffusion, increasing in intensity
with each tap. In standard mode the effect signal is mixed with the dry
sound at 50%. In variation mode the effect signal is 100% wet.
FILTERS
The filters in the delay FILTER section are great tools for shaping the
delay sound, especially when large feedback amounts are used. Each
consecutive Delay tap is fed through the filter, resulting in a progressively
more filtered sound.
With the LP setting, all delay taps are passed through a Low Pass filter
which reduces high frequency content in the delay feedback signal.
The HP setting provides a High Pass filter, removing low frequency
content. This can be useful for making long delay tails sound less
muddy.
The BP setting adds a Band Pass filter to the delay signal. This will
reduce both high and low frequencies, making for a thin and narrow
sound.
ANALOG MODE
There are two different delay modes, the normal (“non-analog”) mode,
and the ANALOG (Shift+Tap/Set). In Analog Mode the pitch of any
sounding repeats is altered if the tempo is changed – much like with
a vintage analog delay. What’s more, the exact character of each
feedback Filter setting differs slightly from when in “non-analog” mode.
In Analog Mode a slight distortion is also introduced into the delay line
with each tap – especially noticeable with larger feedback amounts.
MASTER CLOCK
The Master Clock feature for the Delay section is activated by turning
MST CLK (Shift + Tempo knob) clockwise. This way the delay will be
synced to the tempo set for the Master Clock, in the Program section.
See page 39 for instructions on how this tempo is set.
The Delay tempo will now be expressed in subdivisions of the Master
Clock tempo, ranging from 1/2 to 1/32 notes. Apart from straight
subdivisions/delay taps there are also swing (S), triplet (T) and dotted (D)
options to choose from.
AMP SIM/EQ
The AMP SIM/EQ effects unit combines a three-band equalizer with
sophisticated amplifier and speaker cabinet simulations. It also includes
resonant 24 dB low-pass and high-pass filters. When no Amp Model or
filter is selected, the Amp Sim/EQ section provides a neutral EQ and
tube style overdrive.
DRIVE
The morphable DRIVE provides a tube style overdrive effect or, if an Amp
model is selected, controls the amount of overdrive for the selected
Amp model. The Drive LED indicates that the overdrive is active.
EQ SECTION
A three band equalizer with Bass, sweepable Mid and Treble controls.
The BASS frequency is 100 Hz, the TREBLE frequency is 4 kHz and the
morphable MID frequency can be set between 200 Hz to 8 kHz, using
its FREQ knob. The boost/cut range is +/- 15 dB.
AMP MODEL
The three different amplifier/speaker simulations are selected with the
Selector button in the Amp Model section:
E The Twin and JC amplifier models provide a significant boost to
the treble range of the source sound, especially in non-variation
modes. Depending on the sound source it may be necessary to
counteract this with the EQ or other means of adjusting the source
timbre.
Amp Model Description
TWIN
A simulation of a classic tube amplifier and
speaker cabinet. The VARIATION changes
the frequency response of the amplifier to a
version with less treble boost and a different
mid-range character.
JC
A simulation of a Jazz Chorus speaker cabinet,
powered by a tube amp. The
VARIATION reduces the treble and changes
the mid-range response of the amplifier.
SMALL
A simulation of a Wurlitzer 200A internal
speaker, powered by a tube amp. The
VARIATION represents an even smaller amp
and speaker model.
