40 | NORD STAGE 4 USER MANUAL OS V1.4X
STORE AS
1 To store and name your program, press STORE AS (Shift + Store).
2 Hold down the ABC soft button to bring up a row of alphanumeric
characters and use the dial to select a character for the current
position. Letting go of the ABC button moves the cursor to the
next position. The dial or PAGE 3/4buttons can be used to move
the cursor freely. The Ins soft button is used for inserting a blank
space at the current position and the Del soft button is used for
deleting the currently selected character.
3 To assign your program a category, which may be useful for
retrieving it later on, press down on the Cat soft button and select
one of the categories from the list.
4 Pressing STORE will now bring up the Store Program To screen.
Use the dial and/or PAGE 3/4and Program buttons to select a
location.
5 When a suitable location has been found, press STORE again.
l Naming programs can also be done with the Nord Sound Manager.
PROGRAM DIAL
The PROGRAM dial to the left of the display is used
for selecting Programs and Presets, for setting menu
parameter values and for entering characters in
program names. Pressing SHIFT while turning the dial
activates the LIST view, which will display all programs
or presets in a list:
LIST OPTIONS
The Program list can be navigated either numerically by pressing Num,
alphanumerically with Abc selected or by category when set to Cat.
NUMERIC
In numeric mode programs are displayed by their order in the Program
banks. The dial and the PAGE buttons can be used for navigating the
list.
ABC
In Abc (alphanumeric) mode programs are instead ordered by name. By
pressing down on the Abc soft button, as indicated by the “6“ symbol,
a specific letter or number can be jumped to by selecting it with the dial.
CATEGORY
In Category mode, programs are sorted by their category. By pressing
down on the Cat soft button, as indicated by the “6“ symbol, an
alphabetically sorted list of categories is displayed. The dial can be used
for selecting the desired category.
l In Cat sort mode, the Page buttons can be used for quickly
jumping to the first program in the next category.
PAGE BUTTONS
Program pages are navigated by pressing the
PAGE 3/4 buttons. Each Bank holds 8 pages,
with 8 Programs on each page. These buttons
can also be used for switching between
categories when browsing Programs, Presets
or Pianos in category mode, and for navigating menu settings within the
various menus.
Press BANK 3/4 (Shift + Page buttons) to switch between program
banks.
MIDI AND EXTERN INDICATORS
The MIDI LED, located above the top left corner of the
display, blinks as incoming MIDI messages are received by
the MIDI In port or through USB. Short blinks represent any
incoming MIDI messages whereas longer blinks represent
MIDI that is actually being used by the Nord Stage 4.
The EXTERN LED blinks when MIDI is going out on any of the three
Extern MIDI channels. MIDI that is sent through the Send On Load
function, when a Program is loaded, is represented by a very long blink
of the LED. Read more about Extern and Send On Load in the Extern
chapter, beginning on page 46.
PRESET LIBRARY
The Nord Stage 4 comes with extensive Preset banks for the Organ,
Piano and Synth sections, letting you load complete sounds, including
their effect configurations, into an existing Program. Custom sounds can
also be stored to the Preset banks, allowing for quick recall of individual
sounds when setting up a Program.
BROWSING AND LOADING PRESETS
For the Piano and Synth sections there are two distinct methods for
loading Presets; for an entire Section or for a single Layer, which keeps
other Layers in that Section intact.
The first method is intended for when no other sounds are required for
a Section, allowing for use of Presets made up of multiple Layers. The
second method is useful when combining multiple sounds for use in a
split setup or if using the faders or Layer Scene functionality to switch
between different sounds within the same Program.
i Organ presets are always loaded for the entire Organ Section,
since the Organ A and B layers share the same effects chain.
LOADING PRESETS FOR A SECTION
To browse and load Presets for a Section press the ORGAN, PIANO or
SYNTH buttons in the PRESET LIBRARY area. Upon entering the Preset
screen the focused Preset is coupled with an “E” to indicate that it has
not yet been loaded. When turning the dial the Layers contained in the
selected Preset are loaded for the corresponding Layers of the Synth
Section and the “E” disappears.
R
HIJKLMNOPQRSTUVWXYZ01
STORE PROGRAM AS
ABC DelCat Ins
usty PWM
