7. PRO G R A M | 39
Press down on the TAP/SET button as indicated by the “6“ symbol,
to bring up the Master Clock tempo and settings page. Use the
PROGRAM dial to set the tempo. Press EXIT (Shift) when finished. The
set tempo will be stored with the program, as long as a Store operation
is performed.
When the Master Clock tempo is set, you can select a subdivision of
that tempo for each function that is synchronized to the Master Clock.
Changes that are made to the Master Clock tempo will be followed by
all functions that are synchronized to it.
EXTERNAL SYNC
The Master Clock on the Stage 4 can be controlled by incoming MIDI
clock messages. This is an automatic behavior: As soon as the Stage 4
receives MIDI clock on the MIDI input or the USB MIDI input, the Master
Clock will be synchronized to the incoming external clock.
When the Master Clock is locked to an incoming clock, “external” will be
shown in the display if MST CLK is pressed, together with the incoming
tempo in BPM.
(KBS) KEYBOARD SYNC
On the Master Clock tempo/settings page, Keyboard Sync behavior can
be selected by pressing the KBS soft button.
Off: When set to Off the Clock is not reset by playing the keyboard.
On: When set to On the Clock is reset after lifting all keys and then
playing the keyboard again.
Soft: When set to Soft the Master Clock will only be reset if waiting
longer than one quarter note (in relation to the current tempo) to play the
keyboard, after all keys have been lifted.
PEDAL TAP
Press Shift+Mst Clk to enable the PEDAL TAP function. When active, an
attached pedal can be used for adjusting the master clock tempo by
pressing it repeatedly. Refer to the Pedal Menu section on page 58 for
pedal options and how to set this up.
TRANSPOSE ON/SET
The Nord Stage 4 can be transposed in semitone
steps on a per-program basis, with a range of +6/-6
semitones. Hold the TRANSP (Transpose) button and
set the transposition by turning the Value Dial. Press
the button again to de-activate a transposition.
Transpose settings are saved and recalled as part of a program, and
always affect all Layers of a program.
l To set up a transpose that affects all programs, use the Global
Transpose setting in the System Menu.
PANIC
Press PANIC (Shift+Transp) to execute an internal “All Notes Off”
message and reset of some of the performance parameters. This can for
instance be used if notes get stuck during a MIDI or live performance, or
if all sound should quickly be eliminated for some other reason.
STORE
The STORE button is used for storing an edited
program or preset to a location in the program or
preset banks. Storing a program or preset will overwrite
the existing data in the selected memory location.
i When the Nord Stage 4 is shipped from factory its memory is
protected, in order to avoid accidental overwriting of programs. To
be able to store Programs, The Memory Protect parameter needs
to be set to “Off” in the System menu. Read more on how to do
this on page 56. The Memory Protect function does not affect
the eight Live Mode programs or operations performed through the
Nord Sound Manager.
STORING A PROGRAM
To store a program or preset without changing its name, proceed as
follows:
1 Press the STORE button once. The Store button will start blinking,
and the display will show the name of the program and its location.
2 To select a store location use the dial and/or PAGE/BANK 3/4
buttons.
i To cancel an ongoing Store operation, press SHIFT/EXIT.
3 When a suitable location has been selected, press STORE again to
confirm the operation.
l A program can also be stored to one of the eight Live program
locations. This is done by pressing the LIVE MODE button after
having pressed Store, and then selecting the desired Live program
button. The program at the selected store location can always be
auditioned by playing the keyboard.
STORE PROGRAM TO
C:87
Rusty PWM
