26 | NORD STAGE 4 USER MANUAL OS V1.4X
NORD TRIPLE PEDAL
The Nord Stage 4 is compatible with the Nord Triple Pedal 1 (Nord TP-1)
and the Nord Triple Pedal 2 (Nord TP-2), the latter of which is attached
to a dedicated jack labeled TRIPLE PEDAL.
l The Nord Triple Pedal 1 (Nord TP-1) is attached to the SUSTAIN
PEDAL jack.
The Nord Triple Pedals are comprised of three pedals in one unit and
unlock additional features both within the Piano section of the Nord
Stage 4 as well as a number of highly useful options that are not
specifically related to Piano playing. Settings for these options are found
in the Pedal menu, see page 58 for more details.
The Nord TP-2 requires no additional settings when attached to its
dedicated jack. For pedals attached to the Sustain Pedal jack, make
sure that the Sustain Pedal Type setting in the Pedal menu is set to the
specific type or model that is being used.
i If both the Nord TP-1 and TP-2 are attached to the Nord Stage 4,
the left and middle pedal of the TP-1 unit will be non-functional, as
indicated by the “Sustain Only” text in the Pedals menu.
SUSTAIN AND HALF PEDALING
The right pedal always functions as sustain pedal. With the Nord Triple
Pedals as well as the Nord Single Pedal 2 (Nord SP-2) this can be
used with half pedaling techniques, achieved by pressing the pedal half
way down. In this case the (virtual) dampers are only half-raised, for a
partially dampened sound.
SOSTENUTO
The middle pedal of the Nord Triple Pedals is by default the Sostenuto
pedal. Using this, selected notes can be sustained while other notes
remain unaffected. Notes that are already held down when the pedal
is operated will sustain while subsequent notes, played while the pedal
down is, will not be sustained.
l There are a number of optional functions for the middle pedal, see
page 59 for further details.
SOFT PEDAL
The left pedal on the Nord Triple Pedals is by default the soft pedal, also
known as the Una Corda. When it is pressed down, all played notes will
be slightly lower in volume and also have a slightly more subdued tone
quality.
l There are a number of optional functions for the left pedal, see
page 59 for further details.
TIMBRE
Use the Piano TIMBRE settings to quickly alter the
frequency response and character of the selected
piano sound.
ACOUSTIC PIANO TIMBRE SETTINGS
The SOFT setting gives the sound a subdued and intimate quality by
dampening high frequency content and emphasizing the low end
The MID mode de-emphasizes both high and low frequency ranges,
making for a focused and cutting sound with a prominent mid-range.
The BRIGHT mode emphasizes the high frequency range, producing a
very bright and brilliant sound.
ELECTRIC PIANO TIMBRE SETTINGS
When an Electric Piano is selected, the Timbre settings are tailored
specifically to suit these sounds.
The SOFT setting reduces the treble and bell sound, while retaining a
focused and punchy sound.
The MID setting boosts the upper mid-range, adding “presence” and
cut to the sound.
The BRIGHT setting boosts the upper mid-range and adds brilliance/
treble, giving both presence and clarity to the selected piano sound.
The DYNO 1 and DYNO 2 settings are both based on sounds produced
by a custom preamp and EQ, which was a common addition to tine
based electric pianos in the 70’s and early 80’s. Both settings greatly
enhance the inherent “bell” sound of the electric piano sound. The Dyno
2 setting also boosts the bass register, resulting in a distinctly “mid
scooped” sound.
CLAV SETTINGS
An original Clavinet is equipped with 4 rocker switches which control the
onboard EQ. Most of the combinations produced by these switches are
available on the Nord Stage 4.
Available settings are: Soft, Treble, Soft+Treble, Brilliant, Soft+Brilliant,
Treble+Brilliant, Soft+Treble+Brilliant.
UNISON
The UNISON feature uses transposed voices from
neighbouring keys to create a stereo Unison effect. This
can be used for stereo widening of mono sources such
as electric pianos or for adding width and chorus-like
shimmer to acoustic pianos. At the highest setting larger
degrees of detune is applied. There are three different
degrees of Unison, 1, 2 and 3, ranging from a subtle stereo effect to
more obvious detuning.
