5. PIANO | 25
LIST VIEW
Pressing SHIFT and turning the PIANO SELECT dial activates the LIST
view for piano sounds.
The Piano list top row displays the current type name (“Grand” in this
case), the number of models of that type (9), and the index of the
currently selected model (3).
PIANO INFO
Pressing INFO (Shift + Piano Select) displays some additional info about
the currently selected model, such as its version number and its exact
size.
KB TOUCH
Pianos from the Nord Piano Libary typically have
a very wide dynamic range, and their dynamic
response can be adjusted according to what fits your
preferences or the context of your performance.
The HEAVY setting represents a heavy piano action,
which facilitates playing softly yet expressively. With each increment of
the Touch setting (MEDIUM and LIGHT) less effort is required to play
loudly.
DYNAMIC COMPRESSION
DYN COMP (Dynamic Compression) reduces the dynamic range of a
piano sound by raising its minimum sound level. Choose between the 1,
2 and 3 settings, where 3 provides the most compression. This feature
is useful for maintaining an audible performance and even sound level,
even when playing very softly or dynamically. The dynamic range in
terms of timbre remains intact.
l Unlike the Compressor (Comp) effect in the Effects section, which
affects the attack and contour of the sound (often desired traits
when using compression as an effect) the Dyn Comp feature does
not alter the character of the selected piano.
The Dyn Comp feature is compatible with version 6 piano sounds only.
The version of a selected piano sound can be checked by pressing INFO
(Shift + Piano Select button).
ACOUSTICS
SOFT RELEASE
Activating SOFT RELEASE will add a slightly longer and
less pronounced release to acoustic piano sounds,
equivalent to what happens when you adjust the
damper tension on an acoustic instrument. The added
release is individual for every note and responds
dynamically to the force with which you play. Electric
Piano sounds instead have their release sound
dampened significantly.
i Some Piano types, such as Clavinets and Harpsichords do not
support the Soft Release feature. In these cases the function will be
disabled.
STRING RESONANCE
The STRING RES (String Resonance) feature is made up of two distinct
components:
1 The dedicated pedal down samples, activated when pressing the
sustain pedal, included in the Med, Lrg and XL sizes of Grand and
Upright piano sounds. These were sampled with the sustain pedal
pressed down, capturing the natural ambience and acoustics of the
original instrument.
2 The simulated “sympathetic” String Resonance which occurs when
strings of held notes are caused to vibrate at their fundamental or
harmonic frequencies as other notes are being played.
The amount of “sympathetic” String Resonance can be adjusted in the
Sound Menu, see page 57.
i If a piano is selected that isn’t compatible with the String
Resonance feature, this function is disabled. This applies to e.g.
the small (Sml) versions of the grand pianos and uprights and the
electric pianos.
PED NOISE (PEDAL NOISE)
PED NOISE (Pedal Noise, Shift + Soft Release/String Res) is available if
a Nord Triple Pedal or a Nord Single Pedal 2 is connected to the Nord
Stage 4 (see below). When activated, the mechanical noise that occurrs
with the sustain pedal on an acoustic or electric piano will be recreated.
The Pedal Noise responds dynamically to the force used when the
sustain pedal is operated.
The level of the Pedal Noise can be adjusted in the Sound Menu, see
page 57.
i If the selected piano is not compatible with the Pedal Noise feature,
this function is disabled.
The list itself shows the currently selected model,
indicated by a rectangle, as well as the preceding
and following models.
Piano Grand 3/9
White Grand XL
Royal Grand 3D XL
Velvet Grand L
Grand Imperial L
CatAbc
Num
