24 | NORD STAGE 4 USER MANUAL OS V1.4X
reason why they all sound and feel so authentic.
i When you download piano sounds with the Nord Sound Manager,
these are automatically placed into their corresponding Type.
If a Program references a piano that is currently not downloaded onto
the Nord Stage 4, the type LED will flash, and the display will read
“Piano not found”. If this happens, you can either navigate to another
instrument Model of the selected (or any other) type and select to use
this piano instead, or use the Nord Sound Manager application to
download the missing instrument.
ABOUT PIANO SIZE
Nord Piano Library sounds come in up to four different sizes. Below
is an overview of how Grand and Upright piano sounds differ in
functionality depending on size:
Sml Med Lrg XL
Detailed velocity mapping
3 3 3 3
String resonance for middle range
3
String resonance for entire range
3 3
Fully mapped keyboard
3
Small (Sml) piano files use the least amount of space in the piano
memory as they do not contain any pedal-down String Resonance
samples at all.
The Medium (Med) versions include pedal-down String Resonance
samples for the important middle region of the range.
The Large (Lrg) versions have the pedal-down String Resonance
samples all across the keyboard.
Many pianos are also available in an Extra Large (XL) version. These are
“fully mapped” across the keyboard, meaning that each key on the Nord
matches its exact equivalent on the original instrument. This naturally
results in a significant increase in size.
PIANO PRESETS
The Nord Stage 4 comes with a large selection of complete and ready-
to-use Piano Presets, including effects. These are browsed and loaded
using the PIANO button in the PRESET LIBRARY area of the Program
section. User created sounds can be stored to the Preset Library as
well, for quick and easy recall regardless of which Program is loaded.
Read more about the Preset Library on page 40.
PIANO SELECT
TYPE AND MODEL
Use the TYPE button for selecting the desired type, or category, of piano
sound. These are the six types into which all piano sounds are placed:
TYPE DESCRIPTION
Grand Acoustic and electric grand pianos
Upright Upright pianos
Electric Electric Pianos (tine and reed based)
Clav Clavinets and Harpsichords
Digital Digital and Layer piano sounds
Misc Miscellaneous sounds
Use the PIANO SELECT dial to choose a piano sound within the selected
Type. The Piano Select LEDs indicate the Type of the currently selected
piano model. Depending on Prog View mode (see page 41), which
governs what info is shown in the display, the name of the selected
model may also be shown in the Program area display.
ABOUT THE CLAVINET
On the original Clavinet D6, different pick-up combinations were
selected by pressing a number of rocker switches. This functionality is
faithfully simulated by the Nord Stage 4, which means that all original
Clavinet D6 pickup selections are available.
PICK-UP TYPE DESCRIPTION
Clav Model A: Only the “neck” pick-up; a warmer, less bright sound.
Clav Model B: Only the “bridge” pick-up; a bright sound.
Clav Model C: Both pick-ups on and in phase; a very full sound.
Clav Model D: Both pick-ups 180 degrees out of phase; the
fundamental is almost cancelled out and the sound becomes thin.
l The Clavinet also has its unique set of Piano Timbre settings,
corresponding to EQ options of the original instrument. Read more
on this on page 26.
Pearl Upright L
Melody Pad
2:53
B3 Flute 2
1:27
E:26
Sweet Layers
