11. MENUS | 31
this setting includes both standard, single value, CC messages used for
most panel controls as well as messages sent using the NRPN standard
from the Piano and Sample Select controls. Read more about NRPN
messages on page 33.
Range: Off, Send, Receive, Send & Receive (Default)
PROGRAM CHANGE MODE
This setting determines whether your Nord Piano 6 transmits and/or
receives MIDI program Change Messages, on the MIDI channel.
Range: Off, Send, Receive, Send & Receive (Default)
DEVICE CHANGE MODE
This allows for setting whether the Nord Piano 6 should transmit and/
or receive Device MIDI Messages or not on the Global channel. Devices
refer to physical physical controllers, such as pedals, which generate
and send MIDI but are excluded from the Control Change filtering.
Range: Off, Send, Receive, Send & Receive (Default)
4 - TRANSPOSE MIDI AT
When set to In, active transpose values (global and/or set per program)
are not applied to outgoing MIDI, but only to incoming MIDI data. In Out
mode sent MIDI notes are transposed but not incoming ones.
Range: In (Default), Out
5 - MIDI OUT VELOCITY CURVE
There are three options for how the velocity of outgoing MIDI notes is
scaled. When set to Heavy, the generated MIDI corresponds to the
dynamic range of the Nord Piano 6 Piano engine, and this setting
should be used when playing the Nord Piano 6 in Local Control “Off”
mode from the local keyboard. The Medium and Light curves require
increasingly less effort to generate higher velocity values.
Range: Standard (Heavy, Default), Medium, Light
PEDAL MENU
1 - CONTROL PEDAL
TYPE
The Nord Piano 6 accepts many of the most commonly available control
pedals through its CTRL/VOL PEDAL input. Select a setting here that
matches the pedal being used.
l If a connected pedal is operated while in this menu, a percentage
indicating the range of the connected pedal is displayed.
Range: Roland EV7 (default), Yamaha FC-7, Korg, Fatar/
Studiologic, Nord SP-2
GAIN
This setting allows for adding some gain to the pedal signal. This can be
useful if an attached pedal does not reach its maximum level or setting.
Range: 1 - 10
2 - SUSTAIN PEDAL TYPE
This allows you to select the type of pedal connected to the SUSTAIN
PEDAL jack, in case the functionality of the pedal is reversed (when the
pedal is up, sustain is on and vice versa).
Range: Nord SP-1 (Default), Nord SP-2, Nord TP-1, Normally
Open, Normally Closed
3 - TRIPLE PEDAL FUNCTION
A connected Triple Pedal, whether its a Nord Triple Pedal 1 connected
to the Sustain Pedal jack or a Nord Triple Pedal 2 connected to the
Triple Pedal jack, can be set up to control a number of different features.
The Right pedal always controls Sustain while the Left and Middle
pedals can each control a larger selection of parameters.
Range Left: Una Corda (Default), Synth Vibrato, Program Up, Program
Down
Range Middle: Sostenuto (Default), Synth Vibrato, Program Up, Program
Down
4 - FOOT SWITCH
TYPE
The Foot Switch jack on the Nord Piano 6 accepts a variety of different
pedals, with either one or two buttons/switches. Set the Type parameter
according to the connected model.
If you are unsure of the polarity of the pedal, simply check whether the
chosen functionality works as expected, if not select the other polarity
(Open or Closed).
i The Nord SP-2 pedal, and other continuous type pedals, are not
compatible with the Foot Switch jack.
Range: Single Open, Single Closed, Dual Open, Dual Closed
SW A
The Switch A parameter determines the function of an attached single
pedal, or the first switch of a dual pedal.
Range: Synth Vibrato, Program Up, Program Down
SW B
The Switch B parameter determines the function of the second switch of
a dual pedal and has no effect when a single pedal is connected.
Range: Synth Vibrato, Program Up, Program Down
