7. EFFECTS | 23
PAN 1 & 2
PAN 1 is an automatic panning modulation which smoothly moves the
signal between the left and right sides of the stereo panorama.
The PAN 2 setting provides a harder panning option, more in line with
the traditional “vibrato” effect often used with electric pianos.
SPIN
The SPIN effect emulates the sound of a rotating speaker. This effect is
useful for giving the sound source a sense of motion, where changes
in Rate are carried out in a ramping fashion with the speed of the effect
being gradually changed.
WAH
The WAH (Wah-Wah) effect gives the sound a characteristic, “Quack”-
like character and can be extremely useful on electric pianos and
Clavinets. The Wah-Wah modulation is produced by a resonant lowpass
filter that can be swept across the frequency range using the Mod 1
RATE knob. During the sweep, the filter’s characteristics also changes.
The Wah effect uses the signal’s amplitude to control the filter sweep
range, making the effect “velocity sensitive” (technically referred to as an
“envelope follower”).
l This effect can also be used as a traditional Pedal Wah with an
expression pedal connected to the Vol/Ctrl Ped jack, and the
CTRLPED mode for Mod 1 being engaged.
RM (RING MODULATION)
Ring Modulation (RM) is a type of modulation where two signals are
multiplied with each other, resulting in an in-harmonic “bell like” sound.
On the Nord Piano 6 the instrument signal is multiplied with a sine wave.
The Rate knob adjusts the frequency of the modulating sine wave.
MOD 2
MOD 2 provides a selection of modulation effects, including two types of
Phaser, a Flanger, two Chorus types and a Vibe effect. Each effect has
its rate controlled by the Mod 2 RATE knob while the AMOUNT knob
controls the intensity of the effect.
MONO
By default all effects in the Mod 2 unit operate in stereo. Press MONO
(Shift+Mod 2 selector) to change to mono processing instead.
PHASER 1 & 2
The PHASER effect produces a characteristic “sweep” effect, commonly
used with electric piano sounds. The digital models for the phasers of
the Nord Piano 6 are inspired by classic units such as the Bi Phase and
the Small Stone.
FLANGER
The FLANGER produces a dramatic comb filter effect, giving the sound a
“swooshy” and resonant quality.
CHORUS 1 & 2
The versatile CHORUS 1 effect gives the impression of “widening”, or
with more extreme settings severely detuning, the sound – achieved by
blending a number of modulated copies of the audio signal.
CHORUS 2 is based on a classic pedal effect which in the default stereo
mode provides lush stereo widening, especially when set to lower rates
and amounts. At higher rates and amounts the effect takes on a distinct
vibrato character, especially in the optional Mono operation mode.
VIBE
The VIBE effect draws its inspiration from a classic foot pedal effect and
produces a sound with both pitch-bending and phasing qualities. The
effect is created through a digital model of a staggered series of phasing
filters, unlike the usually aligned filters of a normal phasing effect.
DELAY
The DELAY unit produces echo/repeat effects. The Delay time is set
by tapping the TEMPO button, or by pressing down on it and SET the
tempo using the Program section dial.
l With the Tempo button pressed down, the Delay Feedback knob
can also be used for adjusting the tempo, making for a neat, “one
hand“ short-cut for setting a value.
The FEEDBACK knob controls the number of delay repeats. At the
lowest setting only the initial repeat is heard, while the highest produces
a very long feedback tail.
The DRY/WET knob adjusts the balance between the dry signal and the
delay repeats.
The Delay effect can be set to GLOBAL (Shift+On) mode, which applies
the current settings to all Piano and Sample Synth Layers
PING PONG
With PING PONG (Shift+Tempo) turned on, the delay repeats alternate
between the left and right channels. If short delay times are used, these
repeats will be “asymmetrical” and produce delays that are more like
early reflections in reverb units.
There are three settings to choose from (1, 2 and 3 with both LEDs lit),
giving an increasing amount of pan for the delay repeats.
FB FILTER
The feedback filters, selected with the FB FILTER button, are great tools
