4. PIANO | 13
ABOUT PIANO SIZE
Nord Piano Library sounds come in up to four different sizes. Below
is an overview of how Grand and Upright piano sounds differ in
functionality depending on size:
Sml Med Lrg XL
Detailed velocity mapping
3 3 3 3
String resonance for middle range
3
String resonance for entire range
3 3
Fully mapped keyboard
3
Small (Sml) piano files use the least amount of space in the piano
memory as they do not contain any pedal-down String Resonance
samples at all.
The Medium (Med) versions include pedal-down String Resonance
samples for the important middle region of the range.
The Large (Lrg) versions have the pedal-down String Resonance
samples all across the keyboard.
Many pianos are also available in an Extra Large (XL) version. These are
“fully mapped” across the keyboard, meaning that each key on the Nord
matches its exact equivalent on the original instrument. This naturally
results in a significant increase in size.
ABOUT STRING RESONANCE
For Piano Sizes that support it (see table above), the String Resonance
feature is always active. The String Resonance effect is achieved by a
combination of two distinct components:
1 The dedicated pedal down samples, activated when pressing the
sustain pedal, included in the Med, Lrg and XL sizes of Grand and
Upright piano sounds. These were sampled with the sustain pedal
pressed down, capturing the natural ambience and acoustics of the
original instrument.
2 The simulated “sympathetic” String Resonance which occurs when
strings of held notes are caused to vibrate at their fundamental or
harmonic frequencies as other notes are being played.
PIANO SELECT
TYPE AND MODEL
Use the TYPE button for selecting the desired type, or category, of piano
sound. These are the six types into which all piano sounds are placed:
TYPE DESCRIPTION
Grand Acoustic and electric grand pianos
Upright Upright pianos
Electric Electric Pianos (tine and reed based)
Clav Clavinets and Harpsichords
Digital Digital and Layer piano sounds
Misc Miscellaneous sounds
Use the MODEL dial to choose a piano sound within the selected Type.
The Piano Select LEDs indicate the Type of the currently selected piano
model. Depending on Prog View mode (see page 19), which governs
what info is shown in the display, the name of the selected model may
also be shown in the Program area display.
ABOUT THE CLAVINET
On the original Clavinet D6, different pick-up combinations were
selected by pressing a number of rocker switches. This functionality is
faithfully simulated by the Nord Piano 6, which means that all original
Clavinet D6 pickup selections are available.
PICK-UP TYPE DESCRIPTION
Clav Model A: Only the “neck” pick-up; a warmer, less bright sound.
Clav Model B: Only the “bridge” pick-up; a bright sound.
Clav Model C: Both pick-ups on and in phase; a very full sound.
Clav Model D: Both pick-ups 180 degrees out of phase; the
fundamental is almost cancelled out and the sound becomes thin.
l The Clavinet also has its unique set of Piano Timbre settings,
corresponding to EQ options of the original instrument. Read more
on this on page 15.
Pearl Upright M
EP2 Ideal Timbre
Super M Pad
L
Pearl Drops
A:23
