14 | NORD PIANO 6 USER MANUAL OS V1.1X
LIST VIEW
Pressing SHIFT and turning the PIANO SELECT dial activates the list view
for piano sounds.
The Piano list top row displays the current type name (“Grand” in this
case), the number of models of that type (8), and the index of the
currently selected model (3).
KB TOUCH
Pianos from the Nord Piano Libary typically have
a very wide dynamic range, and their dynamic
response can be adjusted according to what fits your
preferences or the context of your performance.
The HEAVY setting represents a heavy piano action,
which facilitates playing softly yet expressively. With each increment of
the Touch setting (NORMAL and LIGHT) less effort is required to play
loudly.
DYNAMIC COMPRESSION
DYN COMP (Dynamic Compression) reduces the dynamic
range of a piano sound by raising its minimum sound
level, while retaining differences in timbre. Choose
between the 1, 2 and 3 settings, where 3 provides the
most compression. This feature is useful for maintaining
an audible performance and even sound level, even when
playing very softly or dynamically.
l Unlike the Compressor (Comp) effect in the Effects section, which
affects the attack and contour of the sound (often desired traits
when using compression as an effect) the Dyn Comp feature does
not alter the character of the selected piano.
PEDAL NOISE
PED NOISE (Shift+Dyn Comp) is available if a Nord Triple Pedal or a
Nord Single Pedal 2 is connected to the Nord Piano 6 (see below).
When activated, the mechanical noise that occurrs with the sustain
pedal on an acoustic or electric piano will be recreated. The Pedal
Noise responds dynamically to the force used when the sustain pedal is
operated.
The level of the Pedal Noise can be adjusted in the Sound Menu, see
page 29.
i If the selected piano is not compatible with the Pedal Noise feature,
this function is disabled.
NORD TRIPLE PEDAL
The Nord Piano 6 is compatible with the Nord Triple Pedal 1 (Nord TP-1)
and with the included Nord Triple Pedal 2 (Nord TP-2), the latter being
attached to a dedicated jack labeled TRIPLE PEDAL.
l The Nord Triple Pedal 1 (Nord TP-1) is attached to the SUSTAIN
PEDAL jack.
The Nord Triple Pedals are comprised of three pedals in one unit and
unlock additional features both within the Piano section of the Nord
Piano 6 as well as a number of highly useful options that are not
specifically related to Piano playing. Settings for these options are found
in the Pedal menu, see page 30 for more details.
The Nord TP-2 requires no additional settings when attached to its
dedicated jack. For pedals attached to the Sustain Pedal jack, make
sure that the Sustain Pedal Type setting in the Pedal menu is set to the
specific type or model that is being used.
i If both the Nord TP-1 and TP-2 are attached to the Nord Piano 6,
the left and middle pedal of the TP-1 unit will be non-functional, as
indicated by the “Sustain Only” text in the Pedals menu.
SUSTAIN AND HALF PEDALING
The right pedal always functions as sustain pedal. With the Nord Triple
Pedals as well as the Nord Single Pedal 2 (Nord SP-2) this can be
used with half pedaling techniques, achieved by pressing the pedal half
way down. In this case the (virtual) dampers are only half-raised, for a
partially dampened sound.
SOSTENUTO
The middle pedal of the Nord Triple Pedals is by default the Sostenuto
pedal. Using this, selected notes can be sustained while other notes
remain unaffected. Notes that are already held down when the pedal
is operated will sustain while subsequent notes, played while the pedal
down is, will not be sustained.
l There are a number of optional functions for the middle pedal, see
page 30 for further details.
SOFT PEDAL
The left pedal on the Nord Triple Pedals is by default the soft pedal, also
known as the Una Corda. When it is pressed down, all played notes will
be slightly lower in volume and also have a slightly more subdued tone
quality.
l There are a number of optional functions for the left pedal, see
page 30 for further details.
The list itself shows the currently selected model,
indicated by a rectangle, as well as the preceding
and following models.
Piano Grand 3/8
White Grand
Royal Grand 3D
Soft Grand
Velvet Grand
Grand Imperial
XL
XL
L
L
L
