NORD MODULAR G2 V1.4x 13. Module reference: MIDI group
Page 259
A
PPLICATION
EXAMPLE
The NoteSend module in combination with the
NoteSeq module makes it possible to automatically
send out the sequencer’s note data to a Patch in another
Slot or to external MIDI equipment. Connect the
NoteSeq Control signal output to the NoteSend Note
input and the NoteSeq Trig signal output to the
NoteSend Gate input. If you need longer Gate input
pulses on the NoteSend module, use a logic Pulse
module between the NoteSeq and NoteSend modules
to increase the periods. Set desired Velocity level with
the knob and set the Note number to ‘E4’. Select MIDI
channel on the NoteSend module and you’re set.
C
TRL
R
CV
The MIDI Controller Receive module can be used to
control things in the Patch based on incoming external
MIDI Controller data.
R
CV
OUTPUT
Every time a new MIDI CC value is received on the selected CC# and MIDI channel, a high logic pulse
is output from the Rcv output. This signal can be used to trig different events in the Patch, for example
from external button parameters.
V
AL
OUTPUT
The Val output transmits the MIDI CC values received on the selected CC# and MIDI channel. See also
"Common MIDI module parameters”.
N
OTE
R
CV
The MIDI Note Receive module works like sort of a
MIDI Note detector and can be used for controlling
things in the Patch when receiving a specific incoming
MIDI Note number. These modules are perfect when you want to control parts of the Patch from
different MIDI channels.
N
OTE
KNOB
Set the MIDI Note number to respond to. All other received MIDI Note numbers are disregarded.
G
ATE
OUTPUT
Every time a MIDI Note On message is received on the selected Note number and MIDI channel, the
Gate output transmits a high logic signal. When a MIDI Note Off message is received on the selected
Note number and MIDI channel, the Gate output transmits a low logic signal.
V
EL
OUTPUT
The Vel output transmits the MIDI Velocity values received on the selected Note number and MIDI
channel. See also "Common MIDI module parameters”.
