13. Module reference: Mixer group NORD MODULAR G2 V1.4x
Page 220
L
OG
/L
IN
Switch between Linear and Logarithmic characteristics for the 1/2 knob. ‘Lin’ is suitable for control
signals and ‘Log’ for audio signals. When set to ’Log’ mode both input signals have an attenuation of
about -3dB when the 1/2 knob is in its center position. When in ’Lin’ mode both input signals have an
attenuation of -6dB when the 1/2 knob is in its center position, which is equal to the mathematical mean
of the sum of input 1 and 2 divided by two.
X-
FADE
MODULATION
INPUT
The D
YNAMIC
C
ONTROL
/A
UDIO
modulation input of the X-fade module. Connect a modulator here.
The amount of modulation is controlled with the knob [A
TTENUATOR
T
YPE
I].
1/2
KNOB
Sets the initial mix of the two signals. Clicking on the triangle will set the mix to an equal amount of both
signals.
L
INEAR
Click to select linear crossfade characteristics instead of logarithmic. See also "Common Mixer
parameters”.
F
ADE
1-2
This is a fader with one input and two outputs, and a
fader rotary knob to fade the input signal between the
two outputs.
F
ADE
MODULATION
INPUT
The D
YNAMIC
C
ONTROL
/A
UDIO
modulation input of the X-fade module. Connect a modulator here.
The amount of modulation is controlled with the knob [Attenuator Type I].
L/R
KNOB
With the L/R knob you fade the input signal between the two outputs. In the 12 o’clock position both
outputs are silent. See also "Common Mixer parameters”.
F
ADE
2-1
This is a fader with two inputs and one output, and a
fader rotary knob to fade between the two input signals.
F
ADE
MODULATION
INPUT
The D
YNAMIC
C
ONTROL
/A
UDIO
modulation input of the X-fade module. Connect a modulator here.
The amount of modulation is controlled with the knob [Attenuator Type I].
1/2
KNOB
With the 1/2 knob you fade the between the two input signals. In the 12 o’clock position the output is
silent. See also "Common Mixer parameters”.
