NORD MODULAR G2 V1.4x 13. Module reference: Mixer group
Page 219
M
IX
F
ADER
This mixer has eight D
YNAMIC
C
ONTROL
/A
UDIO
signal inputs, one Chain input and one output. Each
input is equipped with a separate attenuation slider. The
mixer has an Channel Mute button for each channel for
enabling/disabling the input. Each Channel Mute
button can be labelled. The mixer also has a Pad button
for attenuating all inputs by another -6 dB. See also
"Common Mixer parameters”.
M
IX
S
TEREO
This mixer has six D
YNAMIC
C
ONTROL
/A
UDIO
signal
inputs and a stereo output. Each input is equipped with
a separate attenuation control of [A
TTENUATOR
T
YPE
II] and a Pan knob. The Pan knobs attenuate the middle
of the stereo panorama by -3dB. The mixer also has a
Master Level knob for the output signal. See also
"Common Mixer parameters”
P
AN
This module takes an input signal and outputs it in a
stereo panorama.
L
OG
/L
IN
Switch between Linear and Logarithmic characteristics for the L/R knob. ‘Lin’ is suitable for control
signals and ‘Log’ for audio signals. The ’Log’ setting is similar to a -3dB knob found on studio mixing
desks, to fix what is named ‘the hole in the middle’ of the stereo panorama. When the Pan L/R knob is
in its center position both output channels are attenuated by about -3dB, which is acoustically the correct
balance. When in ’Lin’ setting both output channels are attenuated by -6dB in the center position.
P
AN
MODULATION
INPUT
The D
YNAMIC
C
ONTROL
/A
UDIO
modulation input of the Pan module. Connect a modulator to
modulate the position of the signal in the two outputs. The amount of modulation is controlled with the
knob [A
TTENUATOR
T
YPE
I].
L/R
KNOB
Sets the initial pan position. Click on the triangle to reset the initial position to an equal amount of the
incoming signal at both the outputs.
L
INEAR
Click to select linear Pan characteristics instead of logarithmic. See also "Common Mixer parameters”.
X-F
ADE
This mixer can be modulated by a control signal to
produce a crossfade between two incoming signals.
