NORD MODULAR G2 V1.4x 13. Module reference: Envelope group
Page 201
the“EnvADR” on page 201 or “EnvAHD” on page 201. See also "Common Envelope Generator
parameters”.
E
NV
D
This is a Decay Envelope. It has a Decay time control
and an AM modulation input. The attack time of the
Decay Envelope is immediate, which makes it suitable
for controlling the amplitude of percussive and click sounds where a click at the start of the sound is
desirable. The Env output signal can be used as audio e.g. to generate rhythmic audio clicks. Other
applications could be to control Pitch, Filter and FM modulation. If you want to be able to control Attack
time, check out the "EnvADR”. See also "Common Envelope Generator parameters”.
E
NV
ADR
This is an envelope with two or three stages, Attack and
Decay or Attack, Sustain and Release. In [Rel] mode, the
Sustain level is fixed at maximum level for the duration
of the Keyboard Gate pulse or pulse on the Gate input,
turning the module into an ASR-type envelope generator. When in [Rel] mode the Gate/Trig button
must be set to Gate, else the module will still work as when in [Dcy] mode.
G
ATE
/T
RIG
SCROLL
BUTTON
Select whether the envelope should be gated or trigged.
D
CY
/R
EL
Click to change from Attack and Decay stages to Attack, Sustain and Release stages. The Sustain level is
fixed at maximum level.
E
ND
OUTPUT
This yellow logic output sends out a
logic
HIGH
signal as soon as the
envelope has completed its stages and
the envelope signal is back to zero units.
This signal can be useful for gating or
triggering other modules. Another
interesting application is that you can
connect this output directly to the Gate/Trig input and thus create a repeating envelope signal - like a
sort of shapeable “LFO” (see figure). You will have to set the Gate/Trig button to Trig for this to work.
In this case the Envelope will restart itself after it has finished its envelope shape. See also "Common
Envelope Generator parameters”.
E
NV
AHD
The Attack-Hold-Decay envelope is an envelope with
three stages: Attack, Hold and Release. The AHD
Envelope is well suited for audio gating applications, for
example. See also "Common Envelope Generator
parameters”.
