13. Module reference: Envelope group NORD MODULAR G2 V1.4x
Page 200
• P
OS
: Positive Unipolar signal starting from 0 units, going up to +64
units and then down to 0 units again.
• P
OS
I
NV
: Positive Unipolar signal starting from +64 units, going
down to 0 units and then up to +64 units again, i.e. an inverted sig
-
nal.
• N
EG
: Negative Unipolar signal starting from -64 units, going up to 0
units and then down to -64 units again.
• N
EG
I
NV
: Negative Unipolar signal starting from 0 units, going
down to -64 units and then up to 0 units again.
• B
IP
: Bipolar signal with a range of 64 units and its sustain level at 0
(the MultiEnv can have user definable sustain level in this mode).
• B
IP
I
NV
: Bipolar inverted signal with a range of 64 units and its sus-
tain level at 0 (the MultiEnv can have user definable sustain level in
this mode).
Note! The Multi-Envelope module has full range (-64 to 64 units) in Bipolar and Inverted Bipolar mode.
INPUT
The D
YNAMIC
C
ONTROL
/A
UDIO
signal input. Here you can patch a bipolar signal to the envelope
controlled amplifter.
O
UTPUT
The D
YNAMIC
C
ONTROL
/A
UDIO
signal output from the envelope controlled amplifter.
Signal: Bipolar.
E
NV
OUTPUT
The blue control signal output from the envelope generator.
Signal: U
NIPOLAR
OR
B
IPOLAR
.
E
NV
ADSR
This is a regular four-stage ADSR (Attack, Decay,
Sustain and Release) envelope. The ADSR Envelope is
well suited for controlling audio signal amplitude, pitch
and filter cut-off frequency, for example. See also
"Common Envelope Generator parameters”.
E
NV
H
This is a Hold Envelope that can be used to gate an
audio signal for a specified duration. It has a Hold time
control and an AM input. The Hold Envelope has an
immediate attack and decay times.This means that when the Hold Envelope is used for controlling the
amplitude of an audio signal, there may be a clicking sound at the beginning and end, due to the
immediate attack and decay times. If you want to be able to control Attack and Release times, check out
Pos:
PosInv:
Neg:
NegInv:
Bip:
BipInv:
