NORD MODULAR G2 V1.4x 13. Module reference: Envelope group
Page 199
S(
USTAIN
)
Sets the sustain level. This level will be held (sustained) for as long as the logic Gate signal is high.
When the logic Gate signal drops to zero, the envelope will proceed with the release stage. The
sustain level is displayed in ‘units’ in the corresponding display box. Range: 0 to 64 units
H(
OLD
Sets the time the envelope should remain at maximum level. The hold time is displayed in
milliseconds or seconds in the corresponding display box. Range: 0.5 ms to 45 s.
R(
ELEASE
)
Sets the release time. When the logic Gate signal drops to zero, the envelope will decrease from
the sustain level to zero with the release time. The release is exponential (or selectable between
exponential and linear in some modules). The release time is displayed in milliseconds or seconds
in the corresponding display box. Range: 0.5 ms to 45 s.
A
TTACK
/D
ECAY
/S
USTAIN
/H
OLD
/R
ELEASE
MODULATION
Some Envelope Generators feature control signal inputs for modulating
the envelope segments. You can adjust the level of each control signal by
turning the corresponding rotary knob of [A
TTENUATOR
T
YPE
I]. Note
that the A, D, H and R control inputs handles bipolar control signals.
Positive control signals shortens the times and negative control signals
increase the times. With the H parameter it is the other way around.
G
RAPHS
All Envelope Generator modules features a graph which displays the envelope shape. Any
sustain level is indicated with an orange line; the rest of the envelope segments are green.
There is also a yellow horizontal line which indicates the zero level of the envelope.
O
UTPUT
T
YPE
SCROLL
BUTTON
With the Output Type scroll button you determine how the envelope control signal should be
output and affect the envelope controlled amplifter. There are six different alternatives:
