7
• Feed the pump unit's power cable through the rectangular opening on
the side of the tub module, directing the inlet filter downwards and
inwards.
• The power switch is visible through the rectangular hole. Hook the
convex tab on the back of the pump box assembly against the lower
edge of the rectangular hole.
• Check that the bath drain plug is securely fitted
• Place the parts cleaning tray on the shelves on the walls of the tub.
Ensure that the nozzle of the flexible metal fluid outlet tube is facing
inwards and downwards towards the centre of the bath Figure D1.
• Fill the unit with sufficient water-based degreasing solution to cover the
entire pump (approx. 45 litres).
NOTE!
• Carefully follow the instructions for mixing, use and safety of the
degreasing solution before use.
ATTENTION: Only dedicated workshop washer fluids may be used
as degreasers in this type of equipment. Fluids containing
petroleum-based, flammable or volatile substances (e.g. containing
ethanol, solvents, etc.) must not be used in the washer.
• Make sure that the cleaning solution level completely covers the pump,
otherwise it will not function properly.
• Plug the power cord into an approved, grounded and GFI-equipped
power outlet
• Set the power switch fig. B6 to position I "On". The parts washer is now
ready for use.
WASHINGTON WORK
• Open the flap Fig. A1, switch on the pump, make sure there is sufficient
cleaning solution in the chamber.
• Place the parts to be cleaned in the parts tray in Fig. B3.
• Apply the cleaning solution to the part to be washed. Wait for the
cleaning solution to flow completely over the surface of the part, wetting
it completely. Wait for the solution to soften the grease and dirt, then
use a suitable brush to clean the part to remove stubborn deposits.
• Allow excess solution to run off the parts, then remove them from the
washer and rinse in warm clean water.
• When finished, place the pump in the off position, close the lid and
disconnect the unit.
MAINTENANCE AND STORAGE
• After each hour of cleaning, unplug the unit and check the pump inlet
grille.
• Clean the washer more frequently if you are removing large deposits of
grease and grit. ATTENTION: Failure to clean the pump inlet will result
in reduced air and liquid flow, reduce cleaning effectiveness and may
lead to pump motor failure.
• If you find that the pump inlet grille requires more frequent cleaning, you
will probably need to replace the cleaning solution and remove
accumulated deposits from the bottom of the sump.
• Drain and pour the cleaning solution into suitable containers and
dispose of in accordance with local regulations.
PROBLEM SOLVING
• If the fluid stops flowing or flows sporadically, the pump may not be fully
submerged. The pump must be completely under the surface of the
fluid for it to function properly. Check the fluid level and the position of
the pump. If necessary, top up the fluid and correct the position of the
pump.
• Check the pump liquid inlet for contamination, clean it if necessary. If
cleaning the pump inlet does not restore pump performance, there may
be accumulated dirt and grit in the flexible metal liquid discharge line.
• Unplug the unit and remove the flexible metal fluid outlet tube, check
for obstructions in the tube and remove them if present.
KIT CONTENTS:
• Chamber with a capacity of 76 litres (working volume 45 litres)
• Parts tray
• Flexible, adjustable metal fluid outlet tube with nozzle
• Shelf
• Washer legs 4 pcs.
• Set of bolts, washers and nuts for attaching the legs and shelf.
Rated data
Supply voltage
230V
Supply frequency
50Hz
Degree of protection
IP20
Protection class
I
Total volume of the bathtub
75 l
Bath working volume
45 l
Internal dimensions of the bathtub
71xz470x260
Maximum load of the washer
20 kg
Length of flexible tube
615 mm
Pump capacity
2.7-3.3 l/min
Mass
24 kg
Year of production
2025
10-813 indicates both the type and the designation of the machine
ENVIRONMENTAL PROTECTION
Electrically-powered products should not be disposed of with
household waste, but should be taken to appropriate facilities for
disposal. Contact your product dealer or local authority for information
on disposal. Waste electrical and electronic equipment contains
substances that are not environmentally friendly. Unrecycled
equipment poses a potential risk to the environment and human
health.
"GTX Poland Spółka z ograniczoną odpowiedzialnością" Spółka komandytowa with its
registered office in Warsaw, ul. Pograniczna 2/4 (hereinafter: "GTX Poland ") informs that
all copyrights to the content of this manual (hereinafter: "Manual"), including among
others. All copyrights to the contents of this Manual (hereinafter referred to as "Manual"),
including but not limited to its text, photographs, diagrams, drawings, as well as its
composition, belong exclusively to GTX Poland and are subject to legal protection
pursuant to the Act of February 4, 1994 on Copyright and Related Rights (i.e. Journal of
Laws 2006 No. 90 Item 631 as amended). Copying, processing, publishing, modifying for
commercial purposes the entire Manual as well as its individual elements without the
written consent of GTX Poland is strictly prohibited and may result in civil and criminal
liability.
EC Declaration of Conformity
Manufacturer: GTX Poland Sp. z o.o. Sp.k,
2/4 Pograniczna Street 02-285 Warsaw
Product: Parts washers
Model: 10-812; 10-813
Trade name: NEO TOOLS
Serial number: 00001 ÷ 99999
The product described above complies with the following
documents:
Machinery Directive 2006/42/EC
Electromagnetic Compatibility Directive 2014/30/EU
RoHS Directive 2011/65/EU as amended by Directive 2015/863/EU
And meets the requirements of the standards:
EN 60204-1:2018 EN IEC 55014-1:2021; EN IEC 55014-2:2021; EN
IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021
EN IEC 63000:2018
This declaration relates only to the machinery as placed on the market and
does not include components
added by the end user or carried out by him/her subsequently.
Name and address of the EU resident person authorised to prepare the
technical dossier:
Signed on behalf of:
GTX Poland Sp. z o.o. Sp.k.
2/4 Pograniczna Street
02-285 Warsaw
Paweł Kowalski
Technical Documentation Officer GTX Service
Warsaw, 2025-02-10
DEUTSCH(DE)
ÜBERSETZUNG DER ORIGINALANLEITUNG
Werkstatt-Waschmaschine: 10-813
HINWEIS: BEVOR SIE DAS GERÄT BENUTZEN, LESEN SIE BITTE
DIESE ANLEITUNG SORGFÄLTIG DURCH UND BEWAHREN SIE SIE
ZUM NACHSCHLAGEN AUF. PERSONEN, DIE DIE ANLEITUNG
NICHT GELESEN HABEN, DÜRFEN DAS GERÄT NICHT
ZUSAMMENBAUEN, EINSTELLEN ODER BEDIENEN.
BESONDERE SICHERHEITSBESTIMMUNGEN
HINWEIS!
Lesen Sie die Bedienungsanleitung sorgfältig durch, beachten Sie die
darin enthaltenen Warnhinweise und Sicherheitsvorschriften. Das Gerät
wurde für einen sicheren Betrieb konzipiert. Dennoch: Installation,
Wartung und Betrieb des Geräts können gefährlich sein. Wenn Sie die
folgenden Verfahren befolgen, verringern Sie die Gefahr von Bränden,
Stromschlägen und Verletzungen und verkürzen die Installationszeit des
Geräts
