TECHNICAL DATA
The product satises the relevant safety
standards.
Read instructions before use.
WARNING! or CAUTION! or REMEMBER!
Applicable to the given situation.
(general warning sign)
Wear protective goggles.
Parameter description Parameter value
Product name Hose Reel
Model
MSW
-PHR15
MSW
-HR30P
Length of hose [m] 15 30
Length of supply hose
[m]
2 1.20
Working pressure [bar] 160 20
Outer diameter of hose
[mm]
20.5 12
Size of connector M22x1.5 1/4”
EU quick
coupling
Maximum water
temperature [°C]
40
Dimensions [mm] 445x140
x480
260x330
x250
Weight [kg] 30 23
EN
USER MANUAL
8
Product name Hose Reel
Model
MSW
-HR15
MSW
-HR30
Length of hose [m] 20 20
Working pressure [bar] 20
Outer diameter of hose
[mm]
14
Size of connector M22x1.5
Maximum water
temperature [°C]
40
Dimensions [mm] 270x300
x320
270x400
x340
Weight [kg] 23 27
Product name Hose Reel
Model
MSW
-HR45
MSW
-HR20
Length of hose [m] 20 20
Working pressure [bar] 20
Outer diameter of hose
[mm]
14
Size of connector M22x1.5
Maximum water
temperature [° C]
40
Dimensions [mm] 270x400x320
Weight [kg] 30 24.5
Product name Hose Reel
Modell
MSW-HR15W MSW-HR30W
Maximum hose length
[m]
15 30
Working pressure [bar] 20
Size of connector M22x1.5 3/8”
Maximum water
temperature [°C]
100
Dimensions [mm] 280x270x320 270x400x340
Weight [kg] 5 7
g) Remove all adjusting tools or spanners before turning
the device on. A tool or spanner left in the revolving
part of the device may cause injury.
h) Air / water under pressure can cause serious injuries.
Be careful. Wear safety goggles during assembly and
use of the device.
i) The device is not a toy. Children must be supervised to
ensure that they do not play with the device.
j) Only persons who have been properly trained and
familiarised with the operating instructions may
operate this device.
k) In case of hose leakage, disconnect the device from
the supply source. Do not block leaks with foreign
objects (e.g. gloves, cloths, etc.) or body parts (e.g.
hands).
l) Before each use of the device, check that all
connections are properly xed.
m) If the device is used daily, its technical condition
should be checked every day (mainly the hoses and
connections).
2.3. SAFE DEVICE USE
a) Make sure the pressure line is disconnected before
attempting any adjustments, accessory replacements
or doing any work on the device. Such a preventive
measure reduces the risk of an accident.
b) When not in use, store in a safe place, away from
children and people not familiar with the device who
have not read the user manual. The device may pose
a hazard in the hands of inexperienced users.
c) Keep the device in perfect technical condition. Before
each use check for general damage and especially
check for cracked parts or elements and for any other
conditions which may impact the safe operation of the
device. If damage is discovered, hand over the device
for repair before use.
d) Keep the device out of the reach of children.
e) Device repair or maintenance should be carried out by
qualied persons, only using original spare parts. This
will ensure safe use.
f) To ensure the operational integrity of the device, do
not remove factory-tted guards and do not loosen
any screws.
g) When transporting and handling the device between
the warehouse and the destination, observe the
occupational health and safety principles for manual
transport operations which apply in the country where
the device will be used.
h) Clean the device regularly to prevent stubborn grime
from accumulating.
i) Reinforced hoses should be used in places where
there is a high risk of mechanical damage.
j) Do not carry or hang the device by the pressure line.
k) Do not exceed the recommended supply pressure as
this may damage the device.
l) The device is not a toy. Cleaning and maintenance may
not be carried out by children without supervision by
an adult person.
m) Do not run the device when empty.
n) It is forbidden to interfere with the structure of
the device in order to change its parameters or
construction.
o) Check the device regularly for any leaks.
p) Air or liquid under pressure directed at the body may
cause serious injury.
EN
9
2.1. SAFETY IN THE WORKPLACE
a) Make sure the workplace is clean and well lit. A messy
or poorly lit workplace may lead to accidents. Try
to think ahead, observe what is going on and use
common sense when working with the device.
b) If you are unsure about whether the product is
operating correctly or if you nd damage, please
contact the manufacturer’s service centre.
c) Only the manufacturer’s service centre may make
repairs to the product. Do not attempt to make repairs
yourself!
d) Children or unauthorised persons are forbidden to
enter a work station. (A distraction may result in loss
of control over the device).
e) Use the device in a well-ventilated space.
f) The air / water valve should be closed when
connecting and disconnecting the pressure line.
g) Do not direct the pressure line towards yourself or
other people or animals. Pressurized air / water can
cause serious injury.
h) Do not cut o the compressed air / water supply by
crushing or bending pressure hoses.
i) When starting work, gradually increase the air / water
supply to the device to ensure that it works properly. If
you notice any malfunction of the device, immediately
disconnect it from the supply source and contact the
manufacturer's service point.
j) Regularly inspect the condition of the safety labels. If
the labels are illegible, they must be replaced.
k) Please keep this manual available for future reference.
If this device is passed on to a third party, the manual
must be passed on with it.
l) Keep packaging elements and small assembly parts in
a place not available to children.
m) The device should be mounted on a surface free from
any dirt and moisture.
n) Keep your workplace dry. Wet surfaces in the
workplace can cause accidents.
2.2. PERSONAL SAFETY
a) Do not use the device when tired, ill or under the
inuence of alcohol, narcotics or medication which can
signicantly impair the ability to operate the device.
b) The device is not designed to be handled by persons
(including children) with limited mental and sensory
functions or persons lacking relevant experience and/
or knowledge unless they are supervised by a person
responsible for their safety or they have received
instruction on how to operate the device.
c) The device can be handled only by physically t
persons who are capable of handling it, properly
trained, familiar with this manual and trained within
the scope of occupational health and safety.
d) When working with the device, use common sense
and stay alert. Temporary loss of concentration while
using the device may lead to serious injuries.
e) Use personal protective equipment as required
for working with the device, specied in section 1
(Legend). The use of correct and approved personal
protective equipment reduces the risk of injury.
f) Do not overestimate your abilities. When using the
device, keep your balance and remain stable at all
times. This will ensure better control over the device
in unexpected situations.
1. GENERAL DESCRIPTION
The user manual is designed to assist in the safe and
trouble-free use of the device. The product is designed
and manufactured in accordance with strict technical
guidelines, using state-of-the-art technologies and
components. Additionally, it is produced in compliance
with the most stringent quality standards.
DO NOT USE THE DEVICE UNLESS YOU HAVE
THOROUGHLY READ AND UNDERSTOOD THIS
USER MANUAL.
To increase the product life of the device and to ensure
trouble-free operation, use it in accordance with this user
manual and regularly perform maintenance tasks. The
technical data and specications in this user manual are
up to date. The manufacturer reserves the right to make
changes associated with quality improvement.
LEGEND
The original operation manual is in German. Other
language versions are translations from German.
2. USAGE SAFETY
ATTENTION! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in serious injury or even
death.
PLEASE NOTE! Drawings in this manual are for
illustration purposes only and in some details may
dier from the actual product.
The terms "device" or "product" are used in the warnings
and instructions to refer to < Hose Reel >. Do not exceed
the maximum permissible operating pressure! Do not
obstruct the device's inlet and outlet openings.
REMEMBER! When using the device, protect
children and other bystanders.
Rev. 05.04.2022
