10
Rev. 10.11.2021
11
Rev. 10.11.2021
EN
EN
USER MANUAL
Parameter
description
Parameter value
Product name AIR DEHUMIDIFIER
Model
MSW-
DEH1
080A
MSW-
DEH
580B
MSW-
DEH1
080C
MSW-
DEH2
000C
Rated voltage
[V~] / Frequency
[Hz]
230 / 50
Rated power [W] 650
Rated current [A] 2,8
Protection class I
Protection rating
IP
IPX0
Dimensions [mm]
438
x533
x 745
500
x530
x370
435
x667
x942
423
x650
x842
Weight [kg]
34,5/
37,6
36,85/
34,15
34,5/
37,6
34,1/
36,85
Water reservoir
capacity [L]
5,69
Refrigerant type/
amount [g]
R290/230
Area of
application [m
2
]
50-80 50-70 50-80 50-70
Application
temperature [
o
C]
5-38
Air circulation
speed [m
3
/h]
596 570 596 560
Dehumidifying
capacity [L/24h]
43,2
28,7
(27oC,
80%
RH) 51
(30°C,
60%
RH)
35
28,7
(27oC,
80%
RH)
51
(30°C,
60%
RH)
43,2
28,7
(27oC,
80%
RH)
51
(30°C,
60%
RH)
43,2
28,7
(27oC,
80%
RH) 51
(30°C,
60%
RH)
Timer √ √ √ √
Defrost function √ √ √ √
Acoustic pressure
level LpA [dB(A)]
≤52
Maximum
suction/exhaust
side working
pressure [MPa]
3,2/0,7
Heat exchanger
maximum
allowable
pressure [MPa]
3,2
TECHNICAL DATA
Humidity setting
range [% RH]
20-90 (default setting: 50)
1. GENERAL DESCRIPTION
The user manual is designed to assist in the safe and
trouble-free use of the device. The product is designed
and manufactured in accordance with strict technical
guidelines, using state-of-the-art technologies and
components. Additionally, it is produced in compliance
with the most stringent quality standards.
DO NOT USE THE DEVICE UNLESS YOU HAVE
THOROUGHLY READ AND UNDERSTOOD THIS
USER MANUAL.
To increase the product life of the device and to ensure
trouble-free operation, use it in accordance with this user
manual and regularly perform maintenance tasks. The
technical data and specications in this user manual are
up to date. The manufacturer reserves the right to make
changes associated with quality improvement. The device
is designed to reduce noise emission risks to a minimum,
taking into account technological progress and noise
reduction opportunities.
LEGEND
PLEASE NOTE! Drawings in this manual are for
illustration purposes only and in some details may
dier from the actual product.
The original operation manual is written in German. Other
language versions are translations from the German.
2.1. ELECTRICAL SAFETY
a) The plug must t the socket. Do not modify the
plug in any way. Using original plugs and matching
sockets reduces the risk of electric shock.
b) Avoid touching earthed elements such as pipes,
heaters, boilers and refrigerators. There is an
increased risk of electric shock if the earthed device
is exposed to rain, comes into direct contact with a
wet surface or is operating in a damp environment.
Water getting into the device increases the risk of
damage to the device and of electric shock.
c) Do not touch the device with wet or damp hands.
d) Use the cable only for its designated use. Never use
it to carry the device or to pull the plug out of a
socket. Keep the cable away from heat sources, oil,
sharp edges or moving parts. Damaged or tangled
cables increase the risk of electric shock.
e) Do not use the device if the power cord is damaged
or shows obvious signs of wear. A damaged power
cord should be replaced by a qualied electrician or
the manufacturer‘s service centre.
f) To avoid electric shock, do not immerse the cord,
plug or device in water or other liquids. Do not use
the device on wet surfaces.
g) ATTENTION! DANGER TO LIFE! While cleaning, never
immerse the device in water or other liquids.
2.2. SAFETY IN THE WORKPLACE
a) Make sure the workplace is clean and well lit. A
messy or poorly lit workplace may lead to accidents.
Try to think ahead, observe what is going on and use
common sense when working with the device.
b) Do not use the device in a potentially explosive
environment, for example in the presence of
ammable liquids, gases or dust. The device
generates sparks which may ignite dust or fumes.
c) If you discover damage or irregular operation,
immediately switch the device o and report it to a
supervisor without delay.
d) If there are any doubts as to the correct operation
of the device, contact the manufacturer's support
service.
e) Only the manufacturer's service point may repair the
device. Do not attempt any repairs independently!
f) In case of re, use a powder or carbon dioxide
(CO2) re extinguisher (one intended for use on live
electrical devices) to put it out.
g) Children or unauthorised persons are forbidden to
enter a work station. (A distraction may result in loss
of control over the device).
h) Use the device in a well-ventilated space.
i) Regularly inspect the condition of the safety labels. If
the labels are illegible, they must be replaced.
j) Please keep this manual available for future
reference. If this device is passed on to a third party,
the manual must be passed on with it.
k) Keep packaging elements and small assembly parts
in a place not available to children.
l) Keep the device away from children and animals.
m) If this device is used together with another
equipment, the remaining instructions for use shall
also be followed.
REMEMBER! When using the device, protect children
and other bystanders.
2.3. PERSONAL SAFETY
a) Do not use the device when tired, ill or under the
inuence of alcohol, narcotics or medication which
can signicantly impair the ability to operate the
device.
b) The device is not designed to be handled by persons
(including children) with limited mental and sensory
functions or persons lacking relevant experience
and/or knowledge unless they are supervised by
a person responsible for their safety or they have
received instruction on how to operate the device.
c) The device can be handled only by physically t
persons who are capable of handling it, properly
trained, familiar with this manual and trained within
the scope of occupational health and safety.
d) When working with the device, use common sense
and stay alert. Temporary loss of concentration while
using the device may lead to serious injuries.
e) To prevent the device from accidentally switching on,
make sure the switch is on the OFF position before
connecting to a power source.
f) The device is not a toy. Children must be supervised
to ensure that they do not play with the device.
g) The device contains a ammable gas (R290) – it
should be stored in a well-ventilated place, where
there is no open re or gas appliances and electric
heaters in use!
2.4. SAFE DEVICE USE
a) Do not overload the device. Use the appropriate
tools for the given task. A correctly-selected device
will perform the task for which it was designed better
and in a safer manner.
b) Do not use the device if the ON/OFF switch does not
function properly (does not switch the device on and
o). Devices which cannot be switched on and o
using the ON/OFF switch are hazardous, should not
be operated and must be repaired.
c) Disconnect the device from the power supply
before commencement of adjustment, cleaning and
maintenance. Such a preventive measure reduces the
risk of accidental activation.
d) When not in use, store in a safe place, away from
children and people not familiar with the device who
have not read the user manual. The device may pose
a hazard in the hands of inexperienced users.
e) Keep the device in perfect technical condition. Before
each use check for general damage and especially
check for cracked parts or elements and for any other
conditions which may impact the safe operation of
the device. If damage is discovered, hand over the
device for repair before use.
f) Keep the device out of the reach of children.
g) Device repair or maintenance should be carried out
by qualied persons, only using original spare parts.
This will ensure safe use.
h) To ensure the operational integrity of the device, do
not remove factory-tted guards and do not loosen
any screws.
i) When transporting and handling the device between
the warehouse and the destination, observe the
occupational health and safety principles for manual
transport operations which apply in the country
where the device will be used.
The product satises the relevant safety
standards.
Read instructions before use.
The product must be recycled.
WARNING! or CAUTION! or REMEMBER!
Applicable to the given situation (general
warning sign).
ATTENTION! Electric shock warning!
ATTENTION! Fire hazard - ammable
materials!
ATTENTION! Hot surface, risk of burns!
Only use indoors.
2. USAGE SAFETY
ATTENTION! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or
serious injury or even death.
The terms "device" or "product" are used in the warnings
and instructions to refer to AIR DEHUMIDIFIER.
Do not use in the direct vicinity of water tanks. Prevent
the device from getting wet. Risk of electric shock! Do not
cover air inlets / outlets! Do not put your hands or other
items inside the device while it is in use! Do not cover the
ventilation openings!
