12
support@m4sol.com | www.m4sol.com
MS-41Q USER GUIDE
Front Panel Buttons: Please see Page 8.
Remote Control: Please see Page 10
You can connect the Ethernet directly from PC to Quadview Video Process. Please do the following
steps to configure your PC Ethernet setting:
Directly Connect to PC via Ethernet Cable
a. Click Start > Control Panel > Network and Sharing Center
b. Click “Change Adapter Settings”
c. Highlight the network adapter you want to use to connect to the device and click “Change
Settings” of this connection. The “Local Area Connection Properties” window for the selected
network adapter.
d. Highlight the Internet Protocol Version 4 (TCP/IPv4)
e. Click Properties. The Internet Protocol Properties window is relevant to your IT system.
f. Select “Use the following IP Address
for static IP address” and fill in the
details. For TCP/IPv4 you can use any
IP address in the range 192.168.1.1 to
192.168.1.255 (excluding 192.168.1.202).
g. Subnet mask fills in 255.255.255.0.
h. Click “OK”.
i. After doing steps a. through h.
successfully, you can click into Web UI
by typing the 192.168.1.202 IP address in
IE or Chrome.
Configurations
Configurations – Web UI
