20
CLEANING
Remove the transmission casing by removing the screws S (figure 12) and clean around the transmission
and drive belts with a brush or compressed air once or twice a year.
S
S
S
Figure 12
Once every season, the drive wheels should be cleaned internally. Remove both wheels. Clean the gear
wheel and the wheel gear rim of grass and dirt using a brush or compressed air (figure 13).
SHOCK-ABSORBER
Check the shock-absorber and the insulating sleeves twice per
season. Replace in the event of damage or wear (figure 14).
Figure 13
Figure 14
AFTER EACH USE
Remove any grass pulp from the underside of the cutter deck using a non-metallic instrument such as a piece
of wood. Take care not to damage the paintwork.
Examine the cutter blade for any damage. A damaged blade may upset the balance of your mower and cause
excessive vibration. If in doubt refer to your dealer.
Inspect the grass collector and clean it if necessary. If the mesh becomes clogged airflow will be reduced and
impair grass collection.
The handle can be folded down to reduce the amount of storage space required. Take care not to trap any of
the operating cables when folding or unfolding the handle.
Store the mower in a clean, dry area well away from any naked flames, sparks or heat source.
LONG TERM - (if you are not using your mower for more than 28 days)
Give the machine a through clean, paying particular attention to the
underside
Lubricate all moving parts
At the end of the season, empty the fuel tank either by running the
mower out of fuel or tip the machine backwards and onto the back
right wheel to drain the fuel into a suitable container. Drain the carburettor by loosening the drain screw,
retighten the drain screw.
