20
Other Issues (Door Alarm, Mark)
Troubleshooting
To Stop the Alarm (Continuous Short Beeps)
The alarm can be temporarily stopped in the time before the refrigerator is repaired.
Press for at least 5 seconds.
* If performing the above operation does not turn off the alarm, or the alarm periodically sounds, check
peripheral machinery as well.
When the Alarm Cannot be Turned Off
Check that there are no gaps between the door.
When the alarm cannot be turned off, there may be a malfunction and an inspection is required.
Contact the retail store where you purchased the refrigerator.
When the refrigerator will not cool, there may be a malfunction and an inspection is required.
Contact the retail store where you purchased the refrigerator.
When the Mark Blinks Rapidly (About 5 Times per Second)
The refrigerator does not cool at all!
z The refrigerator takes time to cool when you first
start using it. In summer, it may take up to 24 hours
for the inside to be fully cooled.
¨
Page 7
z
If is shown on the operation panel, cancel
demonstration mode.
¨
Page 15
z
Check if the power plug is disconnected or the
circuit breaker has tripped.
In Select case
Ice cream melts
z Store ice cream in the freezer compartment,
not the select case.
Food does not quickly freeze
z With Soft-Freezing, food freezes at about -7 ™C,
so it may take up to about 24 hours for food to
completely freeze.
Soft-Freezing freezes food
z Food appears to freeze just as when it freezes
in the freezer.
z The outer walls heat up significantly
(to about 50 to 60 ™C) immediately
after installation and in summer. This
is because the heat discharging and
condensation prevention pipes are
located on the sides and the top of the
refrigerator. They are required for cooling
and the heat is not an abnormality.
z A heat discharging fan is located
under the refrigerator. Warm air
may be discharged from here.
g
Heat discharging
pipe
Condensation
Prevention Pipes
The outer walls heat up!
The operation panel turns off
automatically!
z If 30 seconds pass without any operation panel
button operations, the display turns off.
When lighting, touch .
¨
Page 8
Frequently asked questions in the initial period and in summer
Before contacting MITSUBISHI ELECTRIC SERVICE CENTRE or its service agent or making a
repair request, check the following.
If the problem persists, contact the retail store where you purchased the refrigerator as soon as possible.
When the Door Alarm Sounds (Door Alarm)
The door alarm (with alarm sound and compartment display) is activated when a door is open for 1 minute or longer.
The pattern of the door alarm sound and the action of compartment display area are as follows depending on how
long the door has been left open.
(Operation panel)
Blinks in synchronization with
the alarm sound.
Compartment display area
Time for which the
door left open
1 minute 2 minutes 3 minutes 4 minutes
Alarm sound
Compartment display area
4 short beeps,
then
2 beeps
4 short beeps,
then 3 long
beeps
4 short beeps,
then 4 long
beeps
After 4 short beeps,
Continuous long
beeps
The compartment display area will blink in synchronization with the alarm sound
Check that the doors are not left ajar or do not have any food trapped
(the packing, the back of the drawer cases). (Check at least once a month.)
Refrigerator and Freezer doors have an opening and closing sensor.
