18
Cleaning the Automatic Ice-Maker
Touch for about 5 seconds.
and will blink for about 1 minute.
● It rinses the ice-maker tray with water from
the water supply tank.
Water supply pipe
For once-a-month
Take out
the water
supply pipe
and wash
with running
water.
The water receptacle and hose
part cannot be removed.
Put the hose in this hole.
Hose partHose part
Water
receptacle
Return back to
original positions.
Return the water supply tank and, if
does not sit in properly, re-set the water
supply pipe. If removal or assembly
are not done correctly, a problem
such as a water leakage will occur.
Make sure to insert the water
supply pipe properly so that there’s
no difference in surface level
between facet A and facet B is.
Remove
the water
supply pipe.
If the water
supply pipe
is tight to remove, place your
finger inside the water receptacle,
remove the corner, and then twist
in the direction of the arrow.
Water supply pipe
Water
receptacle
CornerCorner
Facet A
Facet B
Please do periodic care to prevent the occurrence of water
scale, mold, etc. Please remove water when not making ice.
Take out
ice cubes.
●
●
●
●
Do not use washing agents such as kitchen detergents, benzene or bleach to clean the water filter. It will cause ice to have an odor.
If you use a bleach to clean your water supply tank or lid, please follow product directions carefully.
Assemble the water supply pump properly and firmly. If it is not assembled properly, it may not make ice or it may make a loud sound.
Please attach the lid of water supply tank securely. If the lid is not attached properly, the lid may be out and the water supply tank will fall.
Take ice out of the
ice storage box,
close the freezer door.
Fill water supply tank
with water, put back
in original position.
Repeat 2 or 3 times.
Remove the Ice storage box discard water and ice.
Do not throw out the noise prevention mat.
Ice storage
box
※
Do not use a dishwasher or dryer
because it may cause deformation.
For once-a-week
If mold forms easily in the certain types of water, clean about 2 or 3 times a week.
Water supply tank / Purification filter
Take off the lid
and wash with
water.
(Temperature
tolerance
approx 60
o
C)
Purification filter
Remove and wash with water.
Normally, it does not need replacing.
Please replace for the following reasons:
●
●
●
If something other than water was put in
and the opening got blocked.
If it is damaged.
If mold, etc. is forming.
Water supply pump
For once-a-month
Turn the pump
and take out.
Take out the pipe,
Turn the cap and remove,
Take out the impeller
and wash with water.
Water tank
Pipe
Water supply pump
Impeller※
Pipe
Cap
Water supply
tank
Water supply
pipe
If it is not assembled properly, it may not make ice or it may make
a loud sound. Please check on the following.
The claw on the cap ( )
is turned to put onto the
protruding part ( ) of
the water supply pump.
①
②
②
①
Impeller
Turn
Turn
Water supply tank
※Check to make sure that
the impeller is inside.
Attach the water supply
pump properly to the
water supply tank by
turning and attaching.
Insert the pipe into the
water supply tank opening,
Connect the pipe to the
water supply pump.
※
Check to make sure that there are no substances
at the connection point of the two pipes.
Water supply tank
Pipe
Remove it from
tank.
※
The impeller is made with a
magnetic material. Clean thoroughly
with water, making sure there
are no substances on it.
Cleaning the ice-making tray (rinsing)
Pointers for assembling the water supply pump
To buy another filter, please
inquire at the store where
you bought your unit.
Return parts by following the reverse procedure.
Notice
