17
Before use Operation Cleaning Troubleshooting
When attaching parts, use the backward procedures of removal.
Point when attach Free pocket (large)
Insert the left and right
partway, push the top
of claw part in the center
of free pocket, and fit
the claw part.
※Illustration of MR-HS421EX
Chilled case / Select case /
Cases in the Freezer compartment
Fully pull out the slide case.
Lift the end on your side.
Adjustable shelf / Shelf
Lift up the front side with both hands.
※
If forcefully pulled outward damage may occur to door side.
Please slowly pull and take out.
Pull forward and take out.
If it is attached improperly, it could come
loose and fall, causing injury.
Be careful when attaching and
removing the glass shelf.
Follow the
instructions
Free pocket (large), (small) /
Bottle pocket / Capsule door pocket
※
Lift upward holding right and left sides.
The piece is attached quite firmly.
Draw forward to remove.
Capsule door pocketBottle pocket
If it is attached improperly, it could
come loose and fall, causing injury.
Be careful when attaching
and removing the pocket.
Follow the
instructions
Recessed Portion of the Drip Gutters
Wipe off any dirt, dripping or condensation.
Drip Gutters
Vegetable case
Pull forward.
Adjustable Support Cover
Remove by pulling
forward on
both sides.
※
If difficult to take out, please remove vegetable case
after removing the bottle pocket and the shelf.
