Page 32

Parts Manual - X17 ECO EXTRACTOR

115V Electrical Schematic Reference Numbers

Reference # Description Part Number

S1 SWITCH, BRUSH MOTOR 748602

S2 SWITCH, VACUUM MOTOR 748602

S3 SWITCH, SPRAY & AUXILARY 748603

S4 SWITCH, MICRO MOMENTARY PUMP 748611-1

CB1 CIRCUIT BREAKER, 1.5A BRUSH MOTOR 748695

CB2 CIRCUIT BREAKER, 12A VACUUM MOTOR 748620

CB3 CIRCUIT BREAKER, 1.5A PUMP/SOLENOID & AUXILIARY 748695

M1 MOTOR, BRUSH 831238-2

M2 MOTOR, VACUUM 740089-1

M3 PUMP. WATER 50 PSI 829757-1

M3 OPTIONAL: PUMP. WATER 100 PSI 829757-1HP

Y1 SOLENOID, WATER 740492-1

PG1 GAUGE, BRUSH PRESSURE 748671

BR1 RECTIFIER, BRUSH MOTOR 740202

AUX RECEPTACLE, AUXILARY POWER 741038

X1 TERMINAL BLOCK, HANDLE ASSEMBLY 748616

X2 CONNECTOR, 9 PIN BULKHEAD (FEMALE) 748604

part of X2 CONNECTOR, 9 PIN PLUG (MALE) 748605

part of X2 SEAL, WIRES 9 PIN 748608

part of X2 SEAL, INTERFACE 9 PIN 748609

X3 TERMINAL BLOCK, BASE ASSEMBLY 748615

X4 & X5 CONNECTOR, 3 PIN CAP (FEMALE) 748631

part of X4 & X5 CONNECTOR, 3 PIN PLUG (MALE) 748632

part of X4 & X5 SEAL, WIRES 3P 748633

part of X4 & X5 SEAL, INTERFACE 3 PIN 748634

X6 & X7 CONNECTOR, 2 PIN CAP (FEMALE) 748624

part of X6 & X7 CONNECTOR, 2 PIN PLUG (MALE) 748625

part of X6 & X7 SEAL, WIRES 2 PIN 748626

part of X6 & X7 SEAL, INTERFACE 2 PIN 748627
