After firing the gun, proceed as follows to zero the adjustment

cap.

1. Remove the retaining screw (6) and the adjustment

turret(3).

2. Position the adjustment turret (3) so that the zero mark on

the adjustment turret is aligned with the index mark (5) on

the telescope body.

3. Press down the adjustment turret.

4. Screw the adjustment turret (3) tight with the retaining

screw (6).

11

8

9

10

8. Battery type CR 2032

9. Battery compartment

10. Adjustment wheel illuminated reticle

11. Parallax compensation
