AC Switching Characteriscs
Data Sheet
© 2024 Microchip Technology Inc. and its subsidiaries
DS00003831E - 61
...........continued
Parameter Symbol Min Typ Max Unit Condition
Loss-of-signal
detect (peak
detect range
setting=
high)
9,10
V
DETHIGH
145 — 295 mV Setting = 3
155 — 340 mV Setting = 4
180 — 365 mV Setting = 5
195 — 375 mV Setting = 6
210 — 385 mV Setting = 7
Loss-of-signal
detect (peak
detect range
setting=
low)
9,10
V
DETLOW
65 — 175 mV Setting = PCIe
3, 7
95 — 190 mV Setting = SATA
4, 8
75 — 170 mV Setting = 1
95 — 185 mV Setting = 2
100 — 190 mV Setting = 3
140 — 210 mV Setting = 4
155 — 240 mV Setting = 5
165 — 245 mV Setting = 6
170 — 250 mV Setting = 7
Sinusoidal jitter
tolerance
T
SJTOL
0.34 — — UI >8.5 Gbps –12.7
Gbps
5, 11
0.43 — — UI >8.0–8.5 Gbps
5
0.45 — — UI >3.2–8.0 Gbps
5
0.45 — — UI >1.6 to 3.2
Gbps
5
0.42 — — UI >0.8 to 1.6
Gbps
5
0.41 — — UI 250 to 800
Mbps
5
Total jitter
tolerance with
stressed eye
T
TJTOLSE
0.65 — — UI 3.125 Gbps
5
0.65 — — UI 6.25 Gbps
6
0.7 — — UI 10.3125 Gbps
6
0.7 — — UI 12.7 Gbps
6, 11
Sinusoidal jitter
tolerance with
stressed eye
T
SJTOLSE
0.1 — — UI 3.125 Gbps
5
0.05 — — UI 6.25 Gbps
6
0.05 — — UI 10.3125 Gbps
6
0.05 — — UI 12.7 Gbps
6, 11
CTLE DC gain (all
stages, max
settings)
— 0.1 — 10 dB —
CTLE AC gain (all
stages, max
settings)
— 0.05 — 16 dB —
DFE AC gain (per
5 stages, max
settings)
— 0.05 — 7.5 dB —
Auto adaptive
calibration time
(CTLE)
T
CTLE
12 — 45 ms —
