AC Switching Characteriscs
Data Sheet
© 2024 Microchip Technology Inc. and its subsidiaries
DS00003831E - 55
• LVTTL
• LVCMOS33
• LVCMOS25
• LVCMOS18
• SSTL25I/II
• SSTL18I/II
• HSUL18I/II
For DC input levels, see section DC Input and Output Levels.
Note: Generally, Hysteresis = OFF is recommended. In extremely high noise systems with degraded
reference clock input, Hysteresis = ON may improve results.
5.4.4 Transmier Performance
The following tables describe performance of the transmitter.
Table 5-37. Transceiver Reference Clock Input Terminaon
Parameter Symbol Min (%) Typ (Ω) Max (%) Condition Notes
Single-ended
Thevenin
termination
RefTerm –40 50 +20 VDDI = 1.8V/
1.5V
Thevenin
impedance is
calculated
based on
independent P
and N as
measured at
50% of VDDI.
For 50Ω/75Ω/
150Ω cases, the
nearest
supported
values of
40Ω/60Ω/120Ω
are used.
–40 75 +20 VDDI = 1.8V
–40 150 +20 VDDI = 1.8V/
1.5V
Dierential
termination
RefDiTerm –20 100
1
+20 VICM < 0.8V Measured
across P to N
with 400 mV
bias.
When VICM
complies with
more than one
range, use the
maximum
percentage
tolerance of the
two ranges.
–20 100 +40 0.6V < VICM <
1.65V
–20 100 +80 1.4V < VICM
Power-up
termination
— — >50K — — —
1. Measured at V
CM
= 1.2V and V
ID
= 350 mV.
Note: All pull-ups are disabled at power-up to allow hot plug capability.
The following tables describe the PolarFire transceiver user interface clocks.
Note: Until specied, all modes are non-deterministic. For more information, see PolarFire Family
Transceiver User Guide.
