AC Switching Characteriscs
Data Sheet
© 2024 Microchip Technology Inc. and its subsidiaries
DS00003831E - 56
–STD speed grade is oered for Extended Commercial (E), Industrial (I), Military (M), and Automotive
(T2) temperature grades.
–1 speed grade is oered for Extended Commercial (E), Industrial (I), and Automotive (T2)
temperature grades only.
Table 5-38. Transceiver TX_CLK Range (Nondeterminisc PCS Mode with Global or Regional Fabric Clocks)
Mode STD Min STD Max –1 Min –1 Max Unit
8-bit, max data rate = 1.6 Gbps — 200 — 200 MHz
10-bit, max data rate = 1.6 Gbps — 160 — 160 MHz
16-bit, max data rate = 4.8 Gbps — 300 — 300 MHz
20-bit, max data rate = 6.0 Gbps — 300 — 300 MHz
32-bit, max data rate = 10.3125 Gbps (–STD) / 12.7 Gbps (–1)
1
— 325 — 325 MHz
40-bit, max data rate = 10.3125 Gbps (–STD) / 12.7 Gbps (–1)
1
— 260 — 320 MHz
64-bit, max data rate = 10.3125 Gbps (–STD) / 12.7 Gbps (–1)
1
— 165 — 200 MHz
80-bit, max data rate = 10.3125 Gbps (–STD) / 12.7 Gbps (–1)
1
— 130 — 160 MHz
Fabric pipe mode 32-bit, max data rate = 6.0 Gbps — 150 — 150 MHz
1. For data rates greater than 10.3125 Gbps, V
DDA
must be set to 1.05V mode. See supply tolerance
in the section Recommended Operating Conditions.
–STD speed grade is oered for Extended Commercial (E), Industrial (I), Military (M), and Automotive
(T2) temperature grades.
–1 speed grade is oered for Extended Commercial (E), Industrial (I), and Automotive (T2)
temperature grades only.
Table 5-39. Transceiver RX_CLK Range (Non-Determinisc PCS Mode with Global or Regional Fabric Clocks)
Mode STD Min STD Max –1 Min –1 Max Unit
8-bit, max data rate = 1.6 Gbps — 200 — 200 MHz
10-bit, max data rate = 1.6 Gbps — 160 — 160 MHz
16-bit, max data rate = 4.8 Gbps — 300 — 300 MHz
20-bit, max data rate = 6.0 Gbps — 300 — 300 MHz
32-bit, max data rate = 10.3125 Gbps — 325 — 325 MHz
40-bit, max data rate = 10.3125 Gbps (–STD) / 12.7 Gbps (–1)
1
— 260 — 320 MHz
64-bit, max data rate = 10.3125 Gbps (–STD) / 12.7 Gbps (–1)
1
— 165 — 200 MHz
80-bit, max data rate = 10.3125 Gbps (–STD) / 12.7 Gbps (–1)
1
— 130 — 160 MHz
Fabric pipe mode 32-bit, max data rate = 6.0 Gbps — 150 — 150 MHz
1. For data rates greater than 10.3125 Gbps, V
DDA
must be set to 1.05V mode. See supply tolerance
in the section Recommended Operating Conditions.
–STD speed grade is oered for Extended Commercial (E), Industrial (I), Military (M), and Automotive
(T2) temperature grades.
–1 speed grade is oered for Extended Commercial (E), Industrial (I), and Automotive (T2)
temperature grades only.
