XTreme-EFIS Operating Manual Page 9
3.1.14 Wind speed and direction
The XTreme has the ability to calculate and display the wind speed and direction.
The following variables must be available in order to calculate the wind speed and wind direction
-A valid 2D or 3D GPS fix (COG/SOG)
-Magnetic heading (MGL Avionics magnetic compass is required (SP2/SP6))
-TAS
The wind speed and direction will only be displayed if a valid 2D or 3D GPS fix has not been achieved. The wind speed
and direction will display incorrect information when not in a straight and level flight.
3.1.15 CDI Indicator
The CDI indicator will be displayed at the bottom of the EFIS display when the pilot has selected an active waypoint to fly
to. The CDI bar moves off the center to indicate which direction you must fly in order to stay on the original coarse. If the
CDI is to the left then fly left until the CDI Bar is in the center of the “tick” markers. The “tick” marker scale can be setup in
the “GPS SETUP” menu.
