99-6525
3
Kit Assembly
(Figure A)
(Figure C)
(Figure B)
ISO DIN radio provision with pocket
1. Attach the provided clips to the
radio trim panel (metal clips at the
top; plastic clips at the bottom).
(Figure A)
2. Attach the lower support bracket
to the radio trim panel with climate
controls. (Figure A)
3. Attach the radio brackets to the
pocket using the provided
(2) #8 x 3/8” Phillips pan-head
screws towards the front of the
pocket, and (2) #8 x 1/2” Phillips
flat-head screws towards the
back. Note: If the screws are not
attached this way, the assembly
will not slide into the dash.
(Figure B)
Use countersunk
screws for the rear
mounts on the pocket
Plastic clip
Plastic clip
Metal clips
4. Remove the metal “DIN” sleeve
and trim ring from the aftermarket
radio.
5. Slide the radio into the pocket/
bracket assembly, and then secure
using the screws supplied with
the radio. (Figure C)
Continue to Axxess Interface
Installation
