Unmanaged Rackmountable Switches
Introduction
LED Indication
Power or PWR
On: The switch is powered on.
Off: The switch is powered off or power supply is abnormal.
Flashing: Power supply is abnormal/Loop Prevention function is enabled. (Not for
MS118CP)
1000Mbps
(Only for MS116GS)
On: Running at 1000 Mbps.
Off: Running at 10/100 Mbps or no device is linked to the corresponding port.
Link/Act
General:
On: A device is linked to the corresponding port and running properly.
Flashing: Transmitting or receiving data.
Off: No device is linked to the corresponding port.
Port 17–18/17F–18F of MS118CP:
Green On: Running at 1000 Mbps but no activity.
Green Flashing: Running at 1000 Mbps and is transmitting or receiving data.
Yellow on: Running at 100/10 Mbps but no activity.
Yellow Flashing: Running at 100/10 Mbps and is transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note:
Port 17F–18F of MS118CP only support 1000M SFP module connection, and they only
have Green On/Green Flashing/Off LED indications
PoE Status
(Only for MS118CP)
On: The port is connecting and supplying power to a PD.
Flashing: The PoE power circuit may be in short or the power current may be overloaded
or non-standard PD is connected or the amount of power of the port has exceeded the
power limit.
Off: No PD is connected to the corresponding port or no power is supplied according to
the power limits of the port.
PoE Max
(Only for MS118CP)
On: The remaining PoE power is ≤ 7 W.
Flashing: The remaining PoE power keeps ≤ 7 W after this LED is on for 2 minutes.
Off: The remaining PoE power is > 7 W.
Switch Explanation
Switch Indication
Isolation
Off: Ports can transmit data with each other.
On: The isolated ports cannot transmit data with other downlink ports. They can
transmit data only with the uplink ports.
Loop Prevention
(For MS116GS/MS124GS)
Off: (default) The switch will not try to monitor or address loop-related issues.
On: The switch will monitor and address loop-related issues within the network
structure to prevent disruptions caused by redundant pathing.
Extend
(Only for MS118CP)
Extend Mode switch 1–8 and 9–16 can control the rate and power supply
distance of corresponding ports.
Off: The corresponding ports (1–8/9–16) run at 10/100 Mbps and support PoE
power supply up to 100 m away.
On: The corresponding ports (1–8/9–16) run at 10 Mbps and support PoE power
supply up to 250 m away.
