1
Unmanaged Rackmountable Switches
Introduction
Chapter 1 Introduction
1.1 Product Overview
The Unmanaged Switch provides you with a low-cost, easy-to-use, high-performance, seamless, and
standard upgrade to improve your network to 100 Mbps or 1000 Mbps.
MS118CP is also a Power Sourcing Equipment (PSE*). The RJ45 port 1–16 support the Power over
Ethernet (PoE*) function, which can automatically detect and supply power to those powered devices
(PDs*) complying with IEEE 802.3af and IEEE 802.3at.
Note:
■
*PSE is a device (switch or hub for instance) that will provide power in a PoE setup.
■
*PoE is a technology that describes a system to transmit electrical power, along with data, to
remote devices over standard twisted-pair cable in an Ethernet network.
■
*PD is a device powered by a PSE and thus consumes energy. Examples include powering
IP telephones, wireless LAN access points, network cameras, network hubs, embedded
computers, and so on.
1.2 Appearance
■
Front Panel
The front panel of the switches are shown as the following figures.
Figure 1-1 Front Panel of MS116GS
10/100/1000Mbps RJ45 Port LED Switch
Figure 1-2 Front Panel of MS124GS
10/100/1000Mbps RJ45 Port LED Switch
Figure 1-3 Front Panel of MS118CP
10/100Mbps
RJ45 Port (Port 1-16)
LED SFP Port
(Port 17F-18F)
Switch 10/100/1000Mbps
RJ45 Port (Port 17-18)
