Technical Manual Presence Detector SCN-x360xx.03
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Telephone: +49-2263-880 • knx@mdt.de • www.mdt.de
59
59
4.8 Temperature
Temperature measurement only available with “MR16” “360° L3 TS” and Glass Presence Detectors!
The following picture shows the available settings:
Figure 37: Settings – Temperature
The following table shows the possible settings:
ETS-Text
Dynamic range
[Default value]
Comment
Temperature
measurement
• not active
• active
Activation of the temperature
measurement
Measured temperature
sends on change of
not active
0,1 – 1 K
[0,2 K]
Minimum rate of change for the
current measured value to be sent
Send measured value
cyclically
not active
1 min – 120 min
Defining a fixed period of time after
which the current brightness
measurement value is sent repeatedly
Correction value for
sensor
-80 … 50 x0,1 K
(0)
Setting the value by which the
temperature is corrected
Table 29: Settings – Temperature
With temperature measurement, the temperature in the room can be measured and sent to the bus.
The temperature can be sent to the bus both at an adjustable change and cyclically (at fixed time
intervals).
The measured temperature can be shifted up or down via the "Correction value for sensor"
parameter. For example, a correction value of "50" corresponds to a correction of 5 K.
The following table shows the available communication object:
Number
Name
Length
Usage
140
Temperature – Measured value
2 Byte
Sending the current temperature value
Table 30: Communication object – Temperature
