Technical Manual Presence Detector SCN-x360xx.03
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Telephone: +49-2263-880 • knx@mdt.de • www.mdt.de
58
58
• Scenes
Various setpoints (lux) can be set via up to 8 scenes. This means that the brightness value of
the CL for a room can be changed with a simple press of a button. It is also possible to set
whether triggering the scene switches the CL on directly or only the new value is set. It is also
possible to adopt a changed scene value.
The following table shows the relevant communication objects:
Number
Name
Length
Usage
130
Constant light – Switch On/Off
1 Bit
Object to activate/deactivate control via
external command
131
Constant light – Dimming relative
4 Bit
Manual adjustment of the current
brightness
132
Constant light – Dimming absolute
1 Byte
Adjusting the current brightness to a
new absolute value
134
Constant light – Lock
1 Bit
Locking the control
135
Constant light – Scenes
1 Bit
Controlling scenes
136
Constant light –
Dimming absolute output main
1 Byte
Output for middle group
137
Constant light –
Dimming absolute output wall
1 Byte
Output for wall group
138
Constant light –
Dimming absolute output window
1 Byte
Output for window group
139
Constant light – Status
1 Bit
Sending the current status
Table 28: Communication objects – Constant light control
