Technical Manual Presence Detector SCN-x360xx.03
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Telephone: +49-2263-880 • knx@mdt.de • www.mdt.de
48
48
4.6.1 Procedure for Teach-in with constant light control
In order to be able to use all the advantages of intelligent constant light control, the presence
detector should be set once using the Teach-in procedure. A lux meter is required for this. The
procedure should be as follows:
1. Adjust the parameter “Lux value for Teach-in” to the desired brightness value.
Mostly 400-500 Lux are used.
2. Adjust the Parameter “Teach in value at loading of application” to “hold Teach in values”.
3. Make the desired settings for the constant light function. (see chapter 4.7 Constant light
control)
4. Connect the communication objects for the different light groups with the objects of the
dimming actuator
5. Connect the object “100 - Status absolute dimming value” with the status object of the
dimming actuator for the light band in the middle.
6. Connect the object “99 - Calibration start” with a new group address, if the calibration shall
be activated via the ETS (Group monitor) or with a push button.
7. Download the application.
8. The room must be darkened, or the measurement has to be carried out at dusk. The
constant light control learns the brightness and dimming values of the artificial lighting with
the Teach-in. If the Teach-in is carried out in daylight/sunlight, the measurement is disturbed
and saves incorrect measured values.
9. Activate the Teach-in function by sending a logical 0 to the object “99 - Calibration start”. The
green LED in the presence detector starts flashing with a 1s rhythm. Sending a logical 0 again
causes an interruption of the Teach-in process.
10. Change the illuminance by sending dimming commands (relative or absolute) until the lux
meter displays the set value (lux value for Teach-in) at workplace level (usually 400 - 500 lux).
11. Now send a logical 1 to the object “99 - Calibration start”. The red and green LED flashes
alternating.
12. The presence detector now compares the light measurement, learns the associated dimming
value, and learns the brightness values at different dimming values.
13. After successful completion of the Teach-in process, the green LED flashes quickly for 10
seconds. The control is now automatically reactivated and controlled to the setpoint. If an
error occurs, the process is aborted and the red LED flashes quickly for 10 seconds. This
occurs if, for example, no valid dimming value (status) is received from the dimmer. Then
check point 5 above and repeat the process.
14. If the parameter “use switch on dimming value” is adjusted to “calculate switch on value”,
the switch on value is calculated automatically now.
