Technical Manual Presence Detector SCN-x360xx.03
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Telephone: +49-2263-880 • knx@mdt.de • www.mdt.de
49
49
The light codes for the LEDs can be taken from the following table:
LED behaviour
State
green LED flashes slowly
Teach-in is activated; detector is in TeachIn mode
green and red LED flashes alternately
Teach-in process in progress
green LED flashes fast for 10 sec
Teach-in was successfully completed
red LED flashes fast for 10 sec
Teach-in process failed
Table 24: LED behaviour – Teach-in
The following table shows the relevant communication objects:
Number
Name
Length
Usage
96
Brightness – Threshold switch
1 Bit
Sends the set value when it is exceeded /
fallen below
97
Brightness – Measured value
2 Byte
Measured brightness value
98
Brightness – Set switch-on threshold
for light channels
2 Byte
Here the switch-on threshold Day/Night
(see general setting) can be changed via
object. The threshold that is currently in
operation (Day or Night) is always
changed.
Only applies to light channels.
99
Input Teach-in – Start calibration
1 Bit
Starts the adjustment via Teach-in
100
Input Teach-in –
Status absolute dimming value
1 Byte
Receiving the dimming value status from
the dimming actuator
Table 25: Communication objects – Brightness and Teach-in
