Technical Manual Presence Detector SCN-x360xx.03
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Telephone: +49-2263-880 • knx@mdt.de • www.mdt.de
29
29
4.2.5 External Push Button short/long
Light channel
HVAC channel
The following picture shows the settings for the external push-button inputs:
Figure 20: Settings – External push button short/long
The following table shows the possible settings:
ETS-Text
Dynamic range
[Default value]
Comment
External push button
short/long reacts to
• ON and OFF
• only ON
• only OFF
• toggle on telegram
input
Selection of which telegrams are valid for
the external button
External push button short:
If Night light is active
• switch to Day light
• stay at Night light
Setting what should happen when
external button is shortly pressed while
Night light is active.
For SCN-P360E3.03 only possible from
HW R4.2 onwards
If output "Day" is
already ON
• stay in automatic mode
• switch to manual mode
Setting the operating mode when output
is already ON at "Day".
Visible with setting "switch to Day light".
If output is already ON
• stay in automatic mode
• switch to manual mode
Setting the operating mode when the
output is already ON.
Visible with setting "stay at Night light".
Table 12: Settings – External push button short/long
The external push-button short is used to manually switch between the states of the light channel or
to switch on the light channel in the half-automatic operating mode.
The external push-button long is used to manually switch the light channel ON/OFF.
