Technical Manual Presence Detector SCN-x360xx.03
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Telephone: +49-2263-880 • knx@mdt.de • www.mdt.de
30
30
The external push-button input can be used to switch on the light/HVAC channel independently of a
motion detection. The exact procedures for the "external push-button short/long" are explained in
more detail in chapter 4.2.8 Process diagrams.
The parameters for "idle time" are described in the following chapter 4.2.6 Idle time.
The following table shows the available communication objects:
Number
Name
Length
Usage
3
Light channel 1 - Input –
External push button short
1 Bit
Object for the input of an external push button
4
Light channel 1 - Input –
External push button long
1 Bit
Object for the input of an external push button
63
HVAC - Input –
External push button short
1 Bit
Object for the input of an external push button
64
HVAC - Input –
External push button long
1 Bit
Object for the input of an external push button
Table 13: Communication objects – External push button short/long
4.2.6 Idle time
Light channel
HVAC channel
The idle time defines the time for which the presence detector is locked for further detection after it
has been switched off. Two settings are available for this (here SCN-P360K4.03):
Figure 21: Settings – Idle time
The following settings are available:
ETS-Text
Dynamic range
[Default value]
Comment
Idle time after external
button short is OFF
1 … 30 s
[5 s]
Setting of the time for which the presence
detector is locked for further detection after it
has been switched off via "external push-
button short".
Function for SCN-P360E3.03 only possible
from hardware revision R4.2
Idle time after switch-off
0 … 60 s
[1 s]
Setting the time for which the presence
detector is locked for further detection after
the follow-up time has expired.
Table 14: Settings – Idle time
The parameter "Idle time after external button short OFF" is useful, for example, to leave the room
briefly after switching OFF via the external push-button without avoiding a renewed switching ON of
the light by detection.
